Old 07-13-2006, 03:57 PM   #11
Professor Wizard
MF Moderator

Professor Wizard's Avatar

Join Date: Mar 2005
Vehicle: 2005 Ford Mustang GT Convertable
Location: Missouri
Posts: 3,440
Send a message via Yahoo to Professor Wizard
Default RE: My experience installing the AEM “Brute Force” CAI…

Quote:
ORIGINAL: RW06stang

Looks very good man. Hmm...... how would that do with my Nitrous?

[IMG]local://upfiles/33407/742CD5055F7440C2BAC588F60B3CB503.jpg[/IMG]
I would think it would work better then the factory intake!

Quote:
ORIGINAL: zjdoran7

How much for the shaker hood + paint?
My Shaker was around $850, and cost another $100 to prep and paint!

Quote:
ORIGINAL: Orion_240

Thanks Prof! It looks much better now. I just had a pet peeve with that old intake pipe's red not matching the car's red! ;-)
I noticed it looks like you had a silver OEM air filter cover. Was that a slip-on cover or what?
The other question is what exactly does the Shaker intake do?
I painted the OEM Air Box Cover Silver and then clearcoat...

The Shaker - as designed, acts as a pressurized "Ram Air" air system when you’re moving faster then 20mph. The kit encloses the factory air box so pressure can build up giving your engine more direct cool air.

Installing the AEM, I re-engineered the ductwork from the Shaker to force cool air into the heat shield area of the intake.

Quote:
ORIGINAL: hawgman

Thank Gawd you finally got rid of that fugly red spray painted stock intake tube.
You lucky Haw - - - I was considering painting it Purple with pink metal flake just for you man!


In case you are wondering...

WHAT MODIFICATIONS did I have to make to the Shaker for my AEM CAI?

First - - had to reshape the front mounting bracket which attaches to the front of the Throttle Bore Housing to allocate for the additional distance created by adding the AEM Spacer.

Second -- Had to cut a hole for the MAF Wiring Access. The original access hole location would not allow me to reach the MAF in its new location on the AEM.

Third -- Had to take my dremel and cut a notch out of the side of the heat shield to allow access of the Cold Air Duct coming from my Shaker and entering the space of the AEM Intake.

Forth -- Trimmed the original Shaker Cold Air Duct so it would dump into the AEM Shield.

Here are some of pics of the finished Shaker / AEM Incorporation.
.
.

You can see the original hole for the MAF jack, and the new one I created.
Click the image to open in full size.

.
.
Here you can see where I trimmed out the Heat Shield to create access for the Air Duct...
Click the image to open in full size.

Click the image to open in full size.

.
.
And the finished product...
Click the image to open in full size.

Click the image to open in full size.

Click the image to open in full size.
This ad is not displayed to registered or logged-in members.
Register your free account today and become a member on Mustang Forums!
__________________
-PW (Professor Wizard)

Vv My Sexy Lady vV

05' Torch Red Vert, Red Int, All Options, Remote Start, Chrome GT's, and other stuff! *Sponsored by Dent Devil*
Professor Wizard is offline   Reply With Quote
Old 07-13-2006, 04:02 PM   #12
Remrats1234
3rd Gear Member

Join Date: May 2006
Location:
Posts: 515
Default RE: My experience installing the AEM “Brute Force” CAI…

you have one of the prettiest engines ever! lol
__________________

K&N Typhoon Intake, Bassani Xpipe, Flowmaster Super 40s, Granatelli Twin 62mm T.B., Webelectric Sequential Tail Lights, Pony Grill Insert
Remrats1234 is offline   Reply With Quote
Old 07-13-2006, 07:36 PM   #13
rex7010
3rd Gear Member

Join Date: Mar 2006
Location: Ohio
Posts: 706
Default RE: My experience installing the AEM “Brute Force” CAI…

Nice job.. nice pics.. good job all around..




Rex
__________________
06 GT Auto, Redfire Metallic, With ALL the toys.. C&L w/ SCT & custom tune. FRPP 3.73's.

rex7010 is offline   Reply With Quote
Old 07-17-2006, 05:25 PM   #14
Professor Wizard
MF Moderator

Professor Wizard's Avatar

Join Date: Mar 2005
Vehicle: 2005 Ford Mustang GT Convertable
Location: Missouri
Posts: 3,440
Send a message via Yahoo to Professor Wizard
Default RE: My experience installing the AEM “Brute Force” CAI…

Thanks guys...

Anyone want to do a writeup on installing their CAI?

Especially those who modified the units to be better.
__________________
-PW (Professor Wizard)

Vv My Sexy Lady vV

05' Torch Red Vert, Red Int, All Options, Remote Start, Chrome GT's, and other stuff! *Sponsored by Dent Devil*
Professor Wizard is offline   Reply With Quote
Old 07-17-2006, 05:34 PM   #15
hammeron
6th Gear Member

hammeron's Avatar

Join Date: May 2006
Vehicle: 2006 GT
Location: Nicely done
Posts: 11,738
Default RE: My experience installing the AEM “Brute Force” CAI…

Thanks Professor for the excellent write up. I want to do pretty
much the same thing and was wondering how you incorporate the
shaker and the CAI system (in a functional mode).
__________________
2006 GT Supercharged



Whipple 12psi, Aluminator 8.7:1, Hot Rod cams.
hammeron is offline   Reply With Quote
Old 07-19-2006, 04:49 PM   #16
Mpaint99
2nd Gear Member

Mpaint99's Avatar

Join Date: Jan 2006
Vehicle: 2005 GT Mustang
Location: Illinois
Posts: 415
Default RE: My experience installing the AEM “Brute Force” CAI…

Installed mine with NOS.It was easier then the factory plastic.Had Breenspeed tune my SCT tuner for it and runs like a champ that it is.
__________________
05 GT Mustang,Auto, Dark Mineral Gray.NOS,Added stripes and Hood scoop,Steeda pulleys,SCT Tuner,Brenspeed tune,TCI stall,Coast DS,AEM Induction,Sequential tailights,410s,Kooks LT,Heads & Comp cam stg II.
Mpaint99 is offline   Reply With Quote
Old 07-19-2006, 04:52 PM   #17
Mpaint99
2nd Gear Member

Mpaint99's Avatar

Join Date: Jan 2006
Vehicle: 2005 GT Mustang
Location: Illinois
Posts: 415
Default RE: My experience installing the AEM “Brute Force” CAI…

Cool chrome radiator cover.The steel braided lines are even nicer.
__________________
05 GT Mustang,Auto, Dark Mineral Gray.NOS,Added stripes and Hood scoop,Steeda pulleys,SCT Tuner,Brenspeed tune,TCI stall,Coast DS,AEM Induction,Sequential tailights,410s,Kooks LT,Heads & Comp cam stg II.
Mpaint99 is offline   Reply With Quote
Old 07-19-2006, 07:02 PM   #18
Daniel60
5th Gear Member


Daniel60's Avatar

Join Date: Dec 2004
Vehicle: 2005 Mustang GT
Location: Small walk way by big walk way
Posts: 4,717
Default RE: My experience installing the AEM “Brute Force” CAI…

Professer Your engine is simply beautiful. There is no doubt in my mind that you are definately in the show car thing. Thanks for the illustration.
__________________
Anyhow, the people that buy 2011's will be stoked -- at first. Until 2012 or 2013 when they add a blower or some other piece of candy that sends the 2011 people into the same funk.---- Mudflap






C/L CAI/Brenspeed tunes/Steeda UDPs'/Mac Prochamber with cats/Mac Axlebacks/4.10gears/AmercianMuscle Strut Tower Brace/CDC Billet Grill/GT badges removed/AmericanMuscle Bullet Rims 255/45/18x9 deepdish/5-speed
Daniel60 is offline   Reply With Quote
Old 07-28-2006, 03:24 PM   #19
mikefan20
2nd Gear Member

Join Date: Jul 2005
Location:
Posts: 280
Default RE: My experience installing the AEM “Brute Force” CAI…

Prof. Who did you buy your AEM from?
Did it come with a tuner?
If not, did you need to get a new tune after the install?
__________________

Black on Black 05 GT Manual UIP -SLP Loudmouth - JLT II CAI & SCT tuner B-Speed 93Oct Tune, Spohn LCA's, 4.10's Installed by DezRacing.
mikefan20 is offline   Reply With Quote
Old 07-28-2006, 04:23 PM   #20
Professor Wizard
MF Moderator

Professor Wizard's Avatar

Join Date: Mar 2005
Vehicle: 2005 Ford Mustang GT Convertable
Location: Missouri
Posts: 3,440
Send a message via Yahoo to Professor Wizard
Default RE: My experience installing the AEM “Brute Force” CAI…

Mike...

I got the AEM from AEM...

You do NOT need a tune.. and it will NOT throw any codes... However, you can always get more benefit if you have a tune with a CAI.

I drove it a while with the tune I had already installed with my shaker, then ran by the shop that does my tunes and had it retuned.
__________________
-PW (Professor Wizard)

Vv My Sexy Lady vV

05' Torch Red Vert, Red Int, All Options, Remote Start, Chrome GT's, and other stuff! *Sponsored by Dent Devil*
Professor Wizard is offline   Reply With Quote
