Old 09-03-2009, 01:38 PM   #1
Ponyboy289

Join Date: May 2007
Vehicle: 1965 Hardtop
Location: Mississippi
Posts: 12
Default Cutting rear bumper for dual exhaust?

This Saturday I will be installing the Pypes SFM65 dual exhaust system on my '06. For mufflers, I'll be installing a set of GT take-offs. If anyone else has done this, what did you use to cut the rear bumper fascia for the driver's side exhaust tip? I've got the cutting template from Pypes, but it does not have any suggestions for what tool to use. I was thinking of using a Dremel tool with a cut-off wheel. Anyone got any suggestions?
This ad is not displayed to registered or logged-in members.
Register your free account today and become a member on Mustang Forums!
Ponyboy289 is offline   Reply With Quote
Old 09-03-2009, 03:21 PM   #2
jtstakelin
2nd Gear Member


jtstakelin's Avatar

Join Date: Mar 2009
Vehicle: 2009 Ford Mustang V6 Deluxe
Location: Kentucky
Posts: 384
Default

Quote:
Originally Posted by Ponyboy289 View Post
This Saturday I will be installing the Pypes SFM65 dual exhaust system on my '06. For mufflers, I'll be installing a set of GT take-offs. If anyone else has done this, what did you use to cut the rear bumper fascia for the driver's side exhaust tip? I've got the cutting template from Pypes, but it does not have any suggestions for what tool to use. I was thinking of using a Dremel tool with a cut-off wheel. Anyone got any suggestions?
Before I got my GT bumper, we used a pneumatic body saw. Pro tip, use some blue painters tape to tape the entire area that you will be cutting. this will help prevent the paint from getting chipped. I have a v6 bumper that is already cut that would need to be painted to match!
__________________
jtstakelin is offline   Reply With Quote
Old 09-03-2009, 03:38 PM   #3
157dB
Cut & Paste Expert

157dB's Avatar

Join Date: May 2007
Vehicle: 2007 Pony Package
Location: NW Arkansas
Posts: 13,294
Default

a HOT WIRE

stretched inbetween a homemade 2x4 framework.
Heat the wire with a battery charger and heat
your way thro the bumper cover.
Then a wine bottle with some sandpaper
round it will clean the edge right up....
__________________
NON PUMKIN JACKER
http://www.mustangforums.com/forum/5...-this-car.html
Quote:
Originally Posted by chronos View Post
You and that darn manual! If you like it so much, maybe you should marry it!
157dB is offline   Reply With Quote
Old 09-03-2009, 03:40 PM   #4
Ponyboy289

Join Date: May 2007
Vehicle: 1965 Hardtop
Location: Mississippi
Posts: 12
Default

Quote:
Originally Posted by jtstakelin View Post
Before I got my GT bumper, we used a pneumatic body saw. Pro tip, use some blue painters tape to tape the entire area that you will be cutting. this will help prevent the paint from getting chipped. I have a v6 bumper that is already cut that would need to be painted to match!
Thanks for the tip! I was thinking about the blue painter's tape also, just to keep the paint from getting scratched or flaking on the edge of the cut.

My apologies to all the regulars for posting this question. I just did a more thorough search of the site and I see where this topic is a beaten dead horse. From what I've read, it sounds like the Dremel will work fine. Now I've just got try and keep a steady hand while I saw into a $20,000 plus automobile with a tool I bought at Wal-Mart.
Ponyboy289 is offline   Reply With Quote
Old 09-03-2009, 05:40 PM   #5
Joshspony
3rd Gear Member


Joshspony's Avatar

Join Date: Apr 2009
Vehicle: 2006 Mustang Coupe PP
Location: WI
Posts: 771
Default

Quote:
Originally Posted by 157db View Post
a HOT WIRE

stretched inbetween a homemade 2x4 framework.
Heat the wire with a battery charger and heat
your way thro the bumper cover.
Then a wine bottle with some sandpaper
round it will clean the edge right up....
Thats a good idea, I never thought of that. Sounds a little McGiver, but I'm sure it would work really good.

Quote:
Originally Posted by Ponyboy289 View Post
Thanks for the tip! I was thinking about the blue painter's tape also, just to keep the paint from getting scratched or flaking on the edge of the cut.

My apologies to all the regulars for posting this question. I just did a more thorough search of the site and I see where this topic is a beaten dead horse. From what I've read, it sounds like the Dremel will work fine. Now I've just got try and keep a steady hand while I saw into a $20,000 plus automobile with a tool I bought at Wal-Mart.
Good luck, have a shot of Jack first to steady your hand!
__________________
Show Mods: Tint 35% on front 20% on 1/4s and rear, shorty billet antenna, Gt front and rear bumpers, CDC GT classic chin spoiler (black textured), clear front turn signals, lower grille inserts

Go Mods: Xcharger Xtreme #201, Borla dual exhaust with X pipe & 4" tips, C&L cai w/ Bama tunes, 8.8" w/ 3.73s and Tlok, strut tower brace, lower A-frame brace

Need more mod money!
Joshspony is offline   Reply With Quote
Old 09-04-2009, 05:15 AM   #6
rls82959
3rd Gear Member

rls82959's Avatar

Join Date: Dec 2006
Vehicle: 98 Ram 1500 4x4
Location: Colorado
Posts: 854
Default

I used a dremel with a a tiny drill bit for steel. Go slow with the dremel, the plastic is really thin and the dremel will slice right thru it. And yeah, steady your hand and don't take your eyes off the cut.
__________________
2007 Premium Pony Package | Satin Silver | 5R55S
Interior Upgrade Package | Performance Package
Bama Doug's 87P | 8.8 Rear-FRPP 4.10 | 4" Shaftmasters
GTM's & Pypes X | C&L CAI | CHE K Brace | OEM P&P TB
SMR ST Brace | TCI Ratchet Shifter | 8" Shorty
CDC Sequentials | Flat Black Aeroform Chin Spoiler
Satin Silver Roush Hood Scoop & Vtech 1/4 Louvers
OEM PP Silver 17x8's - F 235/55/17 - R 255/50/17
rls82959 is offline   Reply With Quote
Old 09-04-2009, 12:52 PM   #7
staggolee
4th Gear Member

staggolee's Avatar

Join Date: Mar 2008
Vehicle: 2014 MT V6
Location: Corona, CA
Posts: 1,579
Send a message via AIM to staggolee
Default

Don't forget the template: http://pysales.com/inst/SFM68-69-bumper-cutout02.pdf
Granted you did buy it from pypes, but I don't know if they just ship this to you with your product
__________________

Neck Snappers: Optional 3.31 gears/LSD
Head Turners: Matte Black Super Stripe
"And by the way, if you see my Gremlin, tell her I ended up getting laid when I got a Mustang." - Jon Stewart
staggolee is offline   Reply With Quote
Old 09-04-2009, 10:23 PM   #8
28HopUp
MF Administrator


28HopUp's Avatar

Join Date: May 2005
Vehicle: 66 94 11
Location: Delaware
Posts: 7,981
Send a message via AIM to 28HopUp
Default

I traced the cut-out onto the painters tape applied to that side. Then I used a razor blade to rough cut the hole close to the line. Finally, I wrapped sandpaper around a full soda can and rotated the can back & forth. It worked great. Just don't slip and cut too far.
__________________
To everyone out there, wherever you are. Remember, the light at the end of the tunnel
may be the police chasing you down in their own Mustang.
28HopUp is offline   Reply With Quote
Old 09-05-2009, 01:06 AM   #9
HoorayBeer
2nd Gear Member

HoorayBeer's Avatar

Join Date: Apr 2008
Vehicle: 07 gt
Location: in ny from nj
Posts: 385
Default

dual exhaust will look great. good luck
__________________

I predict future happiness for Americans if they can prevent the
government from wasting the labors of the people under the pretense of taking care of them.
Thomas Jefferson
HoorayBeer is offline   Reply With Quote
Old 09-05-2009, 08:39 AM   #10
157dB
Cut & Paste Expert

157dB's Avatar

Join Date: May 2007
Vehicle: 2007 Pony Package
Location: NW Arkansas
Posts: 13,294
Default

Quote:
Originally Posted by Ponyboy289 View Post
This Saturday I will be installing the Pypes SFM65 dual exhaust system on my '06. I've got the cutting template from Pypes,
Quote:
Originally Posted by staggolee View Post
Don't forget the template: Granted you did buy it from pypes, but I don't know if they just ship this to you with your product
I think they shipped him a template
__________________
NON PUMKIN JACKER
http://www.mustangforums.com/forum/5...-this-car.html
Quote:
Originally Posted by chronos View Post
You and that darn manual! If you like it so much, maybe you should marry it!
157dB is offline   Reply With Quote
