Old 01-28-2007, 10:07 PM   #1
CoolAid
3rd Gear Member

Join Date: Oct 2006
Location: Valley of the Sun
Posts: 824
Default How To: IAC Rev Mod (Fixing the hanging RPMs)

DISCLAIMER: Myself (coolaid12@hotmail.com) and www.mustangforums.com will not be held responsible for damage to your car, engine or components if you decide to attempt this modification using this guide.
[hr]
This is a super simple modification that you can do to your 99-04 Mustang GT 4.6 2v. With this mod you will create a new IAC gasket to fix the annoying RPM "hang" that stock GTs have. Have you ever reved up your engine and had it take forever to get back down to idle? This is what this mod will address and fix.

PROS:
-
RPMs will return back down to idle faster. Makes for cleaner sounding revs without the annoying "hang".
- Engine braking effect will be present. Meaning; when you let off the gas, the car will actually start to slow itself back down instead of coasting.
- Makes the exhaust have the "gargle and pop" sound like an old hot rod when its on the down scale of a rev.
CONS:
- A "hissing" sound may be heard from under your hood when your standing near it. Sounds like a large vaccum leak. I believe this occurs because of the large amount of air restricted to the IAC by this mod.
- The vehicle may not be able to pass certain local emmisions tests. The reason our cars hang the RPMs in the first place is because of some emmisions crap Ford did. (Just keep your old gasket if you have to smog)
- You may have to re-learn the car a bit as far as shifting (manual trans. cars). The RPMs will fall faster and require you to shift a little sooner then normal.
- If you drill the hole too small, the car will not idle correctly. (Just make the hole bigger!)

As you can see, the Pros far outway the Cons, so go get your materials and tools and get to work!
Tools:
- Gasket Material: You can get this at any parts store like NAPA, Auto Zone...etc... It comes in a sheet, just tell 'em you need about 12' x 12' of it. Or, you can even use tin or thin rubber, I used gasket material to insure no air leaks.
- Socket Wrench (A socket extension is recomended)
- 8mm socket
- Ball point pen
- Drill
- 3/16' drill bit
(or even a 3/16' punch may work if no drill or bit is available)
- A cardboard box
- Common household scissors

-1. Remove the PCV hose so you can access the lower IAC bolt, and remove the (2) 8mm bolts holding the IAC to the upper plenum. Remove the gasket. IMPORTANT: Keep the gasket somewhere incase you ever want to reverse this mod and/or you have to get a smog check!
[IMG]local://upfiles/52823/76BD2809C15F4EDE888F69164E973A1E.jpg[/IMG]

-2. Place the stock IAC gasket on the sheet of gasket material, and use a ball point pen to trace the stock gasket onto the sheet of new gasket material. Make sure to trace out the bolt holes on the sides of the gasket as well. Mark an "X" in the center of one of the large holes.
[IMG]local://upfiles/52823/0B56A2C3A75048F59BCF336052965126.jpg[/IMG]

-3. Using common household scissors, carefully cut out the new gasket following the lines you traced.

-4. Set the new cut-out gasket on top of a cardboard box. This will make it easier to drill (or punch) your bolt holes and center hole through the gasket without it ripping in your hands. Drill out your bolt holes using a 3/16' drill bit, you may need to make a circualr motion with the drill in which it will "round" out the holes a little bit more. Test the sise of the hole by trying to push one of your 8mm bolts through the hole. If it doesn't go through, round out the hole a little more until it goes through with a snug and tight fit.
[IMG]local://upfiles/52823/983CE6E3B47149DFAD102952546A6A91.jpg[/IMG]


-5. Using the 3/16' bit (or punch), drill a hole straight through the little "X" you made in the center of one of the large holes. The size of this hole will determine how hard your revs fall or if your car will stay running at all and is the whole purpose of the mod. I've heard of people using 5/32' bits for the IAC hole, I tried a 5/32' bit and my car would not hold an idle and would die as soon as I let my foot off the gas, so I stepped up to 3/16' and all was well. If this happends for you with the 3/16' bit, then keep stepping up the size until your car runs properly and holds a nice idle.

-6. Now put the IAC back on with the new gasket (make sure the hole you drilled is on the side of the large hole in the plenum). Re-connect the PCV hose. IMPORTANT: Do not over-tighten the 8mm bolts back into the plenum!

-7. Fire up the car and check the idle. Make sure it holds an idle around 750-950 RPM or so, basically checking if it is idleing ok. Wait for oil pressure to build...etc... and give it a nice rev. Check to see if the car revs up clean and falls back down to idle with no problems. I've heard a few people talk about how this may affect a cold start, but I did this mod out in 18' F weather and the car fired right up. It won't go into a high idle, but it will idle never the less. ENJOY!!!!

Thanks to www.mustangforums.com and the members of MF.com for the ideas and inspirations for this write-up.

P.S.: Disposable cameras FTL!!!
This ad is not displayed to registered or logged-in members.
Register your free account today and become a member on Mustang Forums!
__________________
'06 Pontiac GTO, LS2 400/400, 4L65E
CoolAid is offline   Reply With Quote
Old 01-28-2007, 10:18 PM   #2
BlackMustang02GT
4th Gear Member

Join Date: May 2006
Location:
Posts: 1,209
Send a message via AIM to BlackMustang02GT
Default RE: How To: IAC Rev Mod (Fixing the hanging RPMs)

This Post FTW. Try It guys this man has put a hell of a lot of time into this! hes been at it all day just for the guys at MF! Thanks Nate!
__________________
Quote:
havok209: Oops.. I thought you actually went out and touched 500 horses... lol just kidding.

R.I.P ......BlackMustang94GT......
BlackMustang02GT is offline   Reply With Quote
Old 01-28-2007, 10:20 PM   #3
ZW99GT
6th Gear Member

ZW99GT's Avatar

Join Date: Nov 2004
Vehicle: 1999 GT
Location: Tennessee
Posts: 7,797
Default RE: How To: IAC Rev Mod (Fixing the hanging RPMs)

AWESOME WRITE - UP!

Thanks alot. Hey, will this affect my A/F ratio at idle? Will it hurt anything on a high compression engine? My car hangs BAD. ALOT worse that a bolt on car.
__________________
408ci 1999 GT.......................................... 2000 PowerStroke Turbo Diesel


ZW99GT is offline   Reply With Quote
Old 01-28-2007, 10:23 PM   #4
rbstang
6th Gear Member

Join Date: Apr 2005
Vehicle: 2002 Mustang GT
Location: Wilmington, NC
Posts: 5,608
Send a message via AIM to rbstang
Default RE: How To: IAC Rev Mod (Fixing the hanging RPMs)

or you could just buy the $1 thing on ebay that fixxes the IAC and save yourself the trouble... but not the less good write up. time for a sticky and a lock
[sm=lockeddance.gif]
__________________

rbstang is offline   Reply With Quote
Old 01-28-2007, 10:24 PM   #5
AJ06GT
5th Gear Member

AJ06GT's Avatar

Join Date: Sep 2006
Vehicle: 2006 Redfire GT Vert
Location: Raleigh, NC
Posts: 2,896
Default RE: How To: IAC Rev Mod (Fixing the hanging RPMs)

I need to do this someday when I have some spare time I guess. Thanks for the write up.
__________________
2006 Mustang GT
2008 BMW E92 335i - GONE!
2003 Mustang Cobra - GONE!
1997 Mustang GT - GONE!
AJ06GT is offline   Reply With Quote
Old 08-23-2008, 10:18 PM   #6
TX97GT
2nd Gear Member

TX97GT's Avatar

Join Date: Apr 2007
Location: east TX
Posts: 267
Default

Is this only for a 99-04?
__________________


MGW, Flowmaster o/r H-pipe, Eibach, Tokico, Saleen wheels, BBK CAI, King Cobra clutch, 4V in the works...
TX97GT is offline   Reply With Quote
Old 08-23-2008, 11:19 PM   #7
defconfire
5th Gear Member

defconfire's Avatar

Join Date: Mar 2007
Vehicle: '99 Mustang GT
Location: Cary/Charlotte, NC
Posts: 3,790
Default

I am curious about the A/F at idle too.
__________________


Current DD: 2002 Electron Blue Z06
-LG Long Tubes
-LG X-pipe
-Vararam Intake
-MAF Delete
-Speed Density Tune
-I wanted the LSX without the F-body attached-


My Baby: - ::SOLD:: -
defconfire is offline   Reply With Quote
Old 09-29-2008, 03:09 AM   #8
002vmod

Join Date: Dec 2007
Location:
Posts: 21
Default

^me2, creating gargling/mini backfiring is an excessive amt of unburnt fuel being burnt near or infront of the cats, not good for your motor and can eventually lead to blowing rings and frying valves, if you have a piggyback ecu or plug n play that you can map on your computer for fine tuning then this would seem reasonable, anyone feel the same? just my opinion, this is a super annoying characteristic in the mustangs, however.
002vmod is offline   Reply With Quote
Old 09-29-2008, 05:43 AM   #9
MachWon04
1st Gear Member

Join Date: May 2008
Vehicle: 04 Mach 1
Location: Cherry Hill, NJ
Posts: 76
Send a message via AIM to MachWon04 Send a message via MSN to MachWon04
Default

Hmm... My mach gargles quite a bit but I do feel like the revs could drop quicker. I'll have to see if the previous owner ever did this.
__________________
JLT RAI, SLP LM2, Pro 5.0 STS
MachWon04 is offline   Reply With Quote
Old 11-19-2008, 02:50 AM   #10
2000AZ5.0GT
5th Gear Member

2000AZ5.0GT's Avatar

Join Date: Jul 2007
Vehicle: 2000 Ford Mustang GT
Posts: 3,717
Default

I believe the AFR at Idle is around ~14.7:1, It would take loosing alot of air to cause a supremely rich condition enough for the gas to ignite in the headers.

You can always change it with a tuner however
__________________

2000AZ5.0GT is offline   Reply With Quote
