Old 10-03-2007, 12:02 PM   #1
Novanutcase
3rd Gear Member

Novanutcase's Avatar

Join Date: Sep 2007
Location: Los Angeles
Posts: 688
Default Headlight Adjustment

Does anyone elses lights point down at the ground like mine do? I had to stick a piece of wood underneath the headlight so that it would point at least somewhat straight ahead so I can drive at night. Is there any way to adjust the angle of the beam? I've tried and tried to figure out how to do this but so far the only solution I have been able to come up with is the block of wood thing!

John
This ad is not displayed to registered or logged-in members.
Register your free account today and become a member on Mustang Forums!
__________________
2003 Mustang GT, Maximum Motorsports Max Grip Box, Wilwood SL6 front/DL4 rear Big Brake Kit, Corbeau Racing Seats, MGW Short Shifter, MAC Long Tube Headers/Prochamber mid pipes/Flowmaster 40, FRPP 4.10 gears/Eaton Posi, TrickFlow Cover, Moser 31 spline Axles, Trickflow 75mm TB/Plenum, UDP
Novanutcase is offline   Reply With Quote
Old 10-03-2007, 01:15 PM   #2
MustangMan00
5th Gear Member


MustangMan00's Avatar

Join Date: Mar 2006
Vehicle: 2000, Ford, Mustang GT
Location: MD, but NC for school
Posts: 2,374
Send a message via AIM to MustangMan00
Default RE: Headlight Adjustment

what yr?....if its a 99-04 theres a lil screw shoudl be a hex wrench u turn that and they can move up and down
__________________

2000 GT (Auto) 425 RWHP 383 RWTQ
Vortech V1 S-Trim Intercooled
http://s72.photobucket.com/albums/i1...=Burnvideo.flv
2002 SVT Focus 151 FWHP 131 FWTQ(DD)
2001 SVT Lightning 435 RWHP 510 RWTQ (Other Toy)
MustangMan00 is offline   Reply With Quote
Old 10-03-2007, 03:12 PM   #3
97modifiedmustangGT
4th Gear Member

97modifiedmustangGT's Avatar

Join Date: Jul 2006
Location:
Posts: 1,399
Send a message via AIM to 97modifiedmustangGT
Default RE: Headlight Adjustment

Not hijacking but let's say it is a SN then how would you adjust, because mine are pointing too high and I always get flashed.
__________________
97modifiedmustangGT is offline   Reply With Quote
Old 10-03-2007, 04:15 PM   #4
97targa
5th Gear Member

Join Date: Apr 2006
Posts: 3,625
Default RE: Headlight Adjustment

Quote:
ORIGINAL: 97modifiedmustangGT

Not hijacking but let's say it is a SN then how would you adjust, because mine are pointing too high and I always get flashed.
ALL MUSTANGS have outer hex screws on the headlamps for adjustment. There are two screws for each! One corrects up/down and the other side/side Don't wedge a piece of wood or a pry bar in there to force your headlights!.. This is the dumbest thing I have ever heard!
97targa is offline   Reply With Quote
Old 10-03-2007, 05:17 PM   #5
Novanutcase
3rd Gear Member

Novanutcase's Avatar

Join Date: Sep 2007
Location: Los Angeles
Posts: 688
Default RE: Headlight Adjustment

Quote:
ORIGINAL: 97targa

Quote:
ORIGINAL: 97modifiedmustangGT

Not hijacking but let's say it is a SN then how would you adjust, because mine are pointing too high and I always get flashed.
ALL MUSTANGS have outer hex screws on the headlamps for adjustment. There are two screws for each! One corrects up/down and the other side/side Don't wedge a piece of wood or a pry bar in there to force your headlights!.. This is the dumbest thing I have ever heard!
Hahaha! It's an '03 GT! So are they the hex screws with the philips head on the inside? Here are some photos of what I have! Can you point out the adjusters?

Click the image to open in full size.

Click the image to open in full size.

John
__________________
2003 Mustang GT, Maximum Motorsports Max Grip Box, Wilwood SL6 front/DL4 rear Big Brake Kit, Corbeau Racing Seats, MGW Short Shifter, MAC Long Tube Headers/Prochamber mid pipes/Flowmaster 40, FRPP 4.10 gears/Eaton Posi, TrickFlow Cover, Moser 31 spline Axles, Trickflow 75mm TB/Plenum, UDP
Novanutcase is offline   Reply With Quote
Old 10-03-2007, 05:49 PM   #6
ShadowDrake
5th Gear Member


Join Date: Aug 2005
Vehicle: 2004 Ford Mustang GT
Location: Whitehall, Michigan
Posts: 2,637
Send a message via AIM to ShadowDrake
Default RE: Headlight Adjustment

Here you are. It's easiest to adjust it with the headlight in the car and on. Just turn it and see which way it goes and adjust it to where it should be. There's specifications in the manual but I don't remember them.

There is no horizontal adjustment... not that I know of anyway, the manual says only the vertical is adjustable.

Click the image to open in full size.
__________________

2004 GT - 40th Anniversary Pkg.
Just another turbo DOHC
IRS Equipped

RIP 2v!
ShadowDrake is offline   Reply With Quote
Old 10-03-2007, 05:50 PM   #7
MustangMan00
5th Gear Member


MustangMan00's Avatar

Join Date: Mar 2006
Vehicle: 2000, Ford, Mustang GT
Location: MD, but NC for school
Posts: 2,374
Send a message via AIM to MustangMan00
Default RE: Headlight Adjustment

right here is the only one i know of, i dont know where the side to side is if there is one

[IMG]local://upfiles/33307/D44E694B627D4443A6577129901F7871.jpg[/IMG]
__________________

2000 GT (Auto) 425 RWHP 383 RWTQ
Vortech V1 S-Trim Intercooled
http://s72.photobucket.com/albums/i1...=Burnvideo.flv
2002 SVT Focus 151 FWHP 131 FWTQ(DD)
2001 SVT Lightning 435 RWHP 510 RWTQ (Other Toy)
MustangMan00 is offline   Reply With Quote
Old 10-03-2007, 08:16 PM   #8
Novanutcase
3rd Gear Member

Novanutcase's Avatar

Join Date: Sep 2007
Location: Los Angeles
Posts: 688
Default RE: Headlight Adjustment

I tried that and it really didn't do anything. I'll try it again. Also, on the passenger side, the bulb cup that amplifies light to the rear diffuser is loose. Is there any way I can get into the actual light to push it back. It seems to have slid forward and is sort of dangling!

John
__________________
2003 Mustang GT, Maximum Motorsports Max Grip Box, Wilwood SL6 front/DL4 rear Big Brake Kit, Corbeau Racing Seats, MGW Short Shifter, MAC Long Tube Headers/Prochamber mid pipes/Flowmaster 40, FRPP 4.10 gears/Eaton Posi, TrickFlow Cover, Moser 31 spline Axles, Trickflow 75mm TB/Plenum, UDP
Novanutcase is offline   Reply With Quote
Old 10-03-2007, 08:22 PM   #9
ShadowDrake
5th Gear Member


Join Date: Aug 2005
Vehicle: 2004 Ford Mustang GT
Location: Whitehall, Michigan
Posts: 2,637
Send a message via AIM to ShadowDrake
Default RE: Headlight Adjustment

Quote:
ORIGINAL: Novanutcase

I tried that and it really didn't do anything. I'll try it again. Also, on the passenger side, the bulb cup that amplifies light to the rear diffuser is loose. Is there any way I can get into the actual light to push it back. It seems to have slid forward and is sort of dangling!

John
The turn doesn't adjust a lot... at about 35-40 feet, a full turn moves the beam about 3" up/down.

There's no real way to get into the light to fix that... your best bet is to see what you can do about it from the bulb hole. You CAN pull the whole headlight apart but you'll never get it to seal back up properly and condensation will form in it all of the time.
__________________

2004 GT - 40th Anniversary Pkg.
Just another turbo DOHC
IRS Equipped

RIP 2v!
ShadowDrake is offline   Reply With Quote
Old 10-03-2007, 09:18 PM   #10
Novanutcase
3rd Gear Member

Novanutcase's Avatar

Join Date: Sep 2007
Location: Los Angeles
Posts: 688
Default RE: Headlight Adjustment

Got it to work! Thanks guys! Now I can see who I'm hitting at night! LOL!

John
__________________
2003 Mustang GT, Maximum Motorsports Max Grip Box, Wilwood SL6 front/DL4 rear Big Brake Kit, Corbeau Racing Seats, MGW Short Shifter, MAC Long Tube Headers/Prochamber mid pipes/Flowmaster 40, FRPP 4.10 gears/Eaton Posi, TrickFlow Cover, Moser 31 spline Axles, Trickflow 75mm TB/Plenum, UDP
Novanutcase is offline   Reply With Quote
