Default 8 or 6 bolt flywheel?

Is there a way to find out if I have a 6 or 8 bolt flywheel without pulling the tranny? It's a 2001 GT, any help is appreciated. I know this is kind of a dumb question but I wasn't sure if there was a specific year that it changed.
This ad is not displayed to registered or logged-in members.
Register your free account today and become a member on Mustang Forums!
__________________


2001 GT Vortech Supercharged
- To many mods to list.
- I put out fires.
2004YellowStang is offline   Reply With Quote
Old 06-17-2008, 12:41 PM   #2
Ryan86272
5th Gear Member

Ryan86272's Avatar

Join Date: Aug 2006
Vehicle: 2002 Ford Mustang GT
Location: same as you.
Posts: 3,287
Send a message via AIM to Ryan86272 Send a message via Yahoo to Ryan86272
Default RE: 8 or 6 bolt flywheel?

6 BOLT FLYHWEEL= GT'S

8 BOLTS = COBRA

__________________

Best 1/4 mi 11.245 @ 122.26 (Redlining at 1k ft mark) Took out the 4.10's, installed some 3.55's. New times soon..
Best 1/8 mile: 7.1xx @ 99.xx mph
Ryan86272 is offline   Reply With Quote
Old 06-17-2008, 01:03 PM   #3
Eagle2000GT
4th Gear Member


Eagle2000GT's Avatar

Join Date: Aug 2007
Vehicle: 2000 Mustang GT
Location: Shelbyville, Indiana
Posts: 1,088
Default RE: 8 or 6 bolt flywheel?

Is it a Windsor or Romeo motor? Early 2001s may have had Windsor motors. Windsor's are 8-bolt and Romeo's are 6-bolt. (Note: That said, I have heard that a few Windsor's were 6-bolt.)

If you're unsure of the motor, Windsor's have 13/14 bolt valve covers. Romeo's have 11 bolt valve covers.
__________________
370 rwhp/377 rwtq
Procharger P1SC; BBK 75mm TB/Plenum
BBK LT Headers/catted mid-pipe
Miezere Electric Water Pump
13" Cobra brakes
Eagle2000GT is offline   Reply With Quote
Old 06-17-2008, 02:00 PM   #4
oxfordgt
6th Gear Member

oxfordgt's Avatar

Join Date: May 2006
Location: ky
Posts: 6,290
Default RE: 8 or 6 bolt flywheel?

Holy crap you guys just hurt my head with your advise.

Look at your door sticker if the is a K under tranny then you have a later 01 model and it a romeo and a 6 bolt crank.
oxfordgt is offline   Reply With Quote
Old 06-17-2008, 02:08 PM   #5
Ryan86272
5th Gear Member

Ryan86272's Avatar

Join Date: Aug 2006
Vehicle: 2002 Ford Mustang GT
Location: same as you.
Posts: 3,287
Send a message via AIM to Ryan86272 Send a message via Yahoo to Ryan86272
Default RE: 8 or 6 bolt flywheel?

Quote:
ORIGINAL: oxfordgt

Holy crap you guys just hurt my head with your advise.

Look at your door sticker if the is a K under tranny then you have a later 01 model and it a romeo and a 6 bolt crank.
I thought 8 bolts were only on Cobras??

My GT, has 6 bolt. Tranny doesnt matter..(unless u just trying to find out Which motor his had.........) Bolts up the same my BUILT Motor with 8 bolts..

Do the 99-01's have different Flywheels?
__________________

Best 1/4 mi 11.245 @ 122.26 (Redlining at 1k ft mark) Took out the 4.10's, installed some 3.55's. New times soon..
Best 1/8 mile: 7.1xx @ 99.xx mph
Ryan86272 is offline   Reply With Quote
Old 06-17-2008, 02:54 PM   #6
oxfordgt
6th Gear Member

oxfordgt's Avatar

Join Date: May 2006
Location: ky
Posts: 6,290
Default RE: 8 or 6 bolt flywheel?

Yes 99-01.5 are windsors and have 8 bolt cranks. They are still cast cranks like the 6 bolt. 99% of the time a mustang with a T45 has a windsor engine in the 99-01 cars. Thats why you check for what tranny you have.
oxfordgt is offline   Reply With Quote
Old 06-17-2008, 04:24 PM   #7
HEAVYMETALMATT
2nd Gear Member


HEAVYMETALMATT's Avatar

Join Date: Dec 2007
Vehicle: 2001 Cobra
Location: Korea... til 2011, thanks Uncle Sam...
Posts: 434
Default RE: 8 or 6 bolt flywheel?

even easier way is to look at your water pump pulley. if its concaved its a 6, if it protrudes forward its an 8, eagle200gt is right though.
__________________

2001 Cobra
12.72@110
HEAVYMETALMATT is offline   Reply With Quote
Old 06-17-2008, 05:12 PM   #8
Perf_white_GT
2nd Gear Member

Perf_white_GT's Avatar

Join Date: Sep 2007
Vehicle: 2000 Mustang GT
Location: Houston, Tx
Posts: 435
Send a message via AIM to Perf_white_GT Send a message via Yahoo to Perf_white_GT
Default RE: 8 or 6 bolt flywheel?

8 bolt cranks in the mo funkin hizzouse!

2000 GT with a winsor motor!
__________________
2000 Performance White GT
Built By: Advanced Racing Dynamics
Tuned By: Houston Performance
Houston, Tx

If I had a small ****... here is where i would list all my mods...

HP/TQ: lets just agree its more than stock



Perf_white_GT is offline   Reply With Quote
Old 06-17-2008, 09:42 PM   #9
pcs
4th Gear Member

pcs's Avatar

Join Date: Jan 2008
Vehicle: 03 cobra
Location: yuma, az
Posts: 1,251
Default RE: 8 or 6 bolt flywheel?

according to sean hyland motorsports, the 8 bolt can handle more ponies than the 6 bolt can,. though if you try to push either to the limit, you break the rods or pistons first.
__________________
2011 suzuki hayabusa
2010 svt raptor
2006 suzuki ltr 450
1985 yamaha tri z 250
1985 honda 250r
1984 honda 200x
pcs is offline   Reply With Quote
Old 05-14-2014, 04:44 PM   #10
ben830

Join Date: May 2014
Vehicle: 1999 Ford Mustang GT
Location: TEXAS
Posts: 5
Default

Im Only resurrecting this thread to let everyone know that I have a Windsor with a 6 bolt crank. Long story short I ordered an 8 bolt for my 99 and when I went to put on the flywheel obviously didn't bolt on so.
