Default is my idle air controller all jacked up?

so basically when i turn on my a/c or defroster my rpms fluctuate from 400-1200. this just started happening after i installed my c&l plenum. that or since it got really cold all of a sudden here and i never had idle probs in the hot weather, that it could be a cold weather problem but i seriously doubt it. i have an sct tuner and i have my idle set at 620ish and the car will idle perfect except when my compressor is activating. so im assuming that my iac is all messed up somehow. when i installed my plenum i was very very careful with that gasket and i dont think i damaged it. but i did notice that the rubber hose coming off of it was nasty looking and had tiny hairline fractures. could that be it. the fractures causing a vacuum leak? or would that throw off my idle all the time and not just when the compressor is running
This ad is not displayed to registered or logged-in members.
Register your free account today and become a member on Mustang Forums!
__________________
2001 Mustang GT turned Fobra
2001 Cobra engine
HP:323 TQ:323 1/4: 13.2 @ 105
masterofthepuppets99 is offline   Reply With Quote
Old 10-23-2009, 08:43 PM   #2
99mustanggt
3rd Gear Member

Join Date: Mar 2004
Vehicle: 99 Mustang GT
Location: Gettysburg,PA
Posts: 582
Default

Sounds like you have a vacuum leak in your climate control hoses and not a problem with the IAC.
__________________

CMS stage 2's,comp springs,and Bullitt intake waiting for install.
Looking for focus fuel pump and ported heads.PM me if you have any.
99mustanggt is offline   Reply With Quote
Old 10-23-2009, 10:20 PM   #3
Lowtryx
2nd Gear Member

Lowtryx's Avatar

Join Date: Aug 2007
Vehicle: 96 GT
Location: Canada
Posts: 175
Default

+1

If it were your IAC you would be getting other symptoms (Most likely stalling or other throttle issues).

Of course, there is no harm in checking. Pull it off and be sure that the spring and valve move freely. Spraying tune up cleaner inside can free it if a little light corrosion is to blame or coking. Although, like I said I don't believe it's your IAC. I'd go with vacuum leaks as well.
__________________
Red 1996 GT
PI Swapped
BBK Shorty Headers
Pypes HFC'd X Pipe
Magnaflow Catback
Fender-Well CAI
Hurst Billet Aluminum Shifter
Rear Window Louver
Drilled/Slotted Rotors with High Perf. Pads
Hood Pins!
Sequential Tail Lights
Awful Looking Stock Rims Painted Gun-Metal
Lowtryx is offline   Reply With Quote
Old 10-24-2009, 03:10 AM   #4
masterofthepuppets99
2nd Gear Member

masterofthepuppets99's Avatar

Join Date: Feb 2009
Vehicle: 2001 Fobra
Location: Portland, Oregon
Posts: 324
Send a message via AIM to masterofthepuppets99
Default

well im gonna check my iac in the morning. and then ill look for a vacuum leak. i swear it has something to do with my c&l plenum since it started happening after that swap or pretty much around the same time. ill get back to you guys tomorrow. thanks
__________________
2001 Mustang GT turned Fobra
2001 Cobra engine
HP:323 TQ:323 1/4: 13.2 @ 105
masterofthepuppets99 is offline   Reply With Quote
Old 10-24-2009, 10:36 AM   #5
Lowtryx
2nd Gear Member

Lowtryx's Avatar

Join Date: Aug 2007
Vehicle: 96 GT
Location: Canada
Posts: 175
Default

Be sure to check all vacuum lines attributed to the Plenum. There are several lines off of the intake which could very easily cause a substantial leak. Check all lines/hoses before your IAC.
__________________
Red 1996 GT
PI Swapped
BBK Shorty Headers
Pypes HFC'd X Pipe
Magnaflow Catback
Fender-Well CAI
Hurst Billet Aluminum Shifter
Rear Window Louver
Drilled/Slotted Rotors with High Perf. Pads
Hood Pins!
Sequential Tail Lights
Awful Looking Stock Rims Painted Gun-Metal
Lowtryx is offline   Reply With Quote
Old 10-24-2009, 03:19 PM   #6
masterofthepuppets99
2nd Gear Member

masterofthepuppets99's Avatar

Join Date: Feb 2009
Vehicle: 2001 Fobra
Location: Portland, Oregon
Posts: 324
Send a message via AIM to masterofthepuppets99
Default

so i checked for vacuum leaks on and all around any lines that could use vacuum. i used wd-40 and sprayed all over. i found nothing. no idle changes. should i use starting fluid instead? or perhaps i should check my climate control vacuum lines...they are controlled by vacuum right? how would i go about doing that


update: cleaned my iac just for kicks. made no difference
__________________
2001 Mustang GT turned Fobra
2001 Cobra engine
HP:323 TQ:323 1/4: 13.2 @ 105

Last edited by masterofthepuppets99; 10-24-2009 at 05:23 PM.
masterofthepuppets99 is offline   Reply With Quote
Old 10-24-2009, 06:34 PM   #7
Frostbitten
4th Gear Member

Join Date: Jul 2006
Location:
Posts: 1,495
Default

your idle should be around 700rpm. Mine is at 750
__________________
03 GT 5spd
Hellion 62mm w/Flowmaster cat back, DSS ProMod shortblock, manley nextek valvesprings, spec stage 3, billet flywheel, UPR kmember with MMR A arms and MMR coilovers, dual 03/04 cobra pumps w/BAP, SCT BA2800, siemens 60lb injectors, sct x3 with speedy dyno tune......532whp/630wtq
Frostbitten is offline   Reply With Quote
Old 10-24-2009, 07:37 PM   #8
Lowtryx
2nd Gear Member

Lowtryx's Avatar

Join Date: Aug 2007
Vehicle: 96 GT
Location: Canada
Posts: 175
Default

Quote:
Originally Posted by Frostbitten View Post
your idle should be around 700rpm. Mine is at 750

Not when he has set it to 650 with his tuner.


Use starting fluid and, like you said check for idle changes. If you have a serious enough vacuum leak it should rev up a bit. Spray around any suspected areas.
__________________
Red 1996 GT
PI Swapped
BBK Shorty Headers
Pypes HFC'd X Pipe
Magnaflow Catback
Fender-Well CAI
Hurst Billet Aluminum Shifter
Rear Window Louver
Drilled/Slotted Rotors with High Perf. Pads
Hood Pins!
Sequential Tail Lights
Awful Looking Stock Rims Painted Gun-Metal
Lowtryx is offline   Reply With Quote
Old 10-24-2009, 10:47 PM   #9
99mustanggt
3rd Gear Member

Join Date: Mar 2004
Vehicle: 99 Mustang GT
Location: Gettysburg,PA
Posts: 582
Default

Pull out your climate control and see if you can see or hear any leaks behind your dash.I wouldnt spray anything in there because you'll be smelling if for awhile if you do.Try carb cleaner instead of WD or starting fluid.
__________________

CMS stage 2's,comp springs,and Bullitt intake waiting for install.
Looking for focus fuel pump and ported heads.PM me if you have any.
99mustanggt is offline   Reply With Quote
Old 10-25-2009, 03:24 AM   #10
masterofthepuppets99
2nd Gear Member

masterofthepuppets99's Avatar

Join Date: Feb 2009
Vehicle: 2001 Fobra
Location: Portland, Oregon
Posts: 324
Send a message via AIM to masterofthepuppets99
Default

thanks alot. i will increase my idle. and ill will try carb cleaner tomorrow( well i guess today lol). ill also pull out my climate controls and take a look around
__________________
2001 Mustang GT turned Fobra
2001 Cobra engine
HP:323 TQ:323 1/4: 13.2 @ 105
masterofthepuppets99 is offline   Reply With Quote
