Old 01-25-2013, 06:00 PM   #11
Repzard
4th Gear Member

Repzard's Avatar

Join Date: Apr 2009
Vehicle: 99 Ford Mustang GT & 97 Cobra SVT
Location: sttesuhcaxaT (The State you love to hate)
Posts: 1,360
Default

Great Write Up !!! Cliffy
Great Info as always
This ad is not displayed to registered or logged-in members.
Register your free account today and become a member on Mustang Forums!
__________________

1997 SVT Cobra #6149 of 6961
Repzard is offline   Reply With Quote
Old 01-25-2013, 06:35 PM   #12
FrostByte
5th Gear Member


FrostByte's Avatar

Join Date: Jun 2006
Vehicle: 04" Ford Mustang GT
Location: NY
Posts: 2,307
Default

Should be a sticky, EVERY WHERE.

What u recommend for me as far as throttle body/intake for my setup. I think improvement here would put me @ limit for my internals (425ish+ rwhp).
__________________
DSG 04" GT, 5 spd - P1SC Procharger 9 lbs - Anderson Power Pipe - 385 rwhp 329 rwtq - Dyno tuned by Performance Dyno - SLP LMII - Bassini X pipe - 3:73 FRRP - Eibach Pro-Kit - Nittos/ Staggerd on 18" GT500 Black chrome wheels - Seq turn - Steeda Short Shifter - Mach 1 grill delete & chin spoiler - Autometer boost & fuel press gauges - Shorty antenna - Smoked head & tail lights - 5K HIDs
FrostByte is offline   Reply With Quote
Old 01-25-2013, 07:01 PM   #13
cliffyk
TECH SAVANT


cliffyk's Avatar

Join Date: Dec 2006
Vehicle: 1998 SL500
Location: Saint Augustine, FL
Posts: 10,909
Default

Quote:
Originally Posted by FrostByte View Post
Should be a sticky, EVERY WHERE.

What u recommend for me as far as throttle body/intake for my setup. I think improvement here would put me @ limit for my internals (425ish+ rwhp).
With stock internals I would not push it that hard and instead keep it down around 400 rwHP. Even that will negatively affect engine life--if you actually use it regularly. I once asked a close friend, who was an engineer for a couple of the "big name" tuner manufacturers for nearly 20 years, before starting his own company, "What is the practical limit for stock PI internals?". With absolutely no hesitation he said "425 HP, you can set your watch by it."

The sintered metal connecting rods are the weak link. But look at it this way, when Ford built the 2003 and 2004 390 fwHP (331 rwHP) Cobra's they changed to a forged rotating assembly--this was not just so they could spend more money, it was because they felt the 2V internals were not up top the task.

As to your TB and plenum needs, any 75 mm TB and aftermarket plenum will pass enough air for the needs of any build with a stock bottom end. Oddly, and somewhat counter-intuitively, the TB and plenum become less of a factor with forced induction. This is because as soon as the boost comes up the intake tract becomes just a large pressure vessel shoving air into the engine--the engine is no longer trying to suck in pulses of air as with running n/a, where intake size and tuning (on both sides of the TB) are prime factors.

A whole different ball game. It's sort of like connecting a 10-foot 3/4" ID hose with no nozzle to a domestic sillcock and measuring the water flow rate. And then switching to a 10-foot 1" OD hose (78% larger). The flow rate will not change by 78%, if at all, because the 3/4" hose was as big as was needed.

On an n/a setup the intake air pulses can stack up, bang into one another and create standing wave harmonics that can actually "suck out" power at certain frequencies (engine rpms). The n/a intake, especially before the TB, is not "just a pipe" as many like to put forth...
__________________
-cliff knight-
SOLD! - 2003 GT, UPR X, FRPP 24lb/h, Magnaflow, PP 70mm TB & plenum,
Delta Force tuned, Steeda UDPs, Ralco flywheel,
RAM HDX clutch, 3.73s, 262 rwHP/305 lb-ft.

New ride (7/1/2013) 1998 Mercedes SL500-5.0L 32V VVT 326/347 HP/tq


Engineering is, at its base, making what you want from what you have.
At its extreme it is making what you want from what you can get.

Last edited by cliffyk; 01-25-2013 at 08:47 PM.
cliffyk is offline   Reply With Quote
Old 01-25-2013, 11:33 PM   #14
FrostByte
5th Gear Member


FrostByte's Avatar

Join Date: Jun 2006
Vehicle: 04" Ford Mustang GT
Location: NY
Posts: 2,307
Default

Im starting to scare myself. I actually understood that.
__________________
DSG 04" GT, 5 spd - P1SC Procharger 9 lbs - Anderson Power Pipe - 385 rwhp 329 rwtq - Dyno tuned by Performance Dyno - SLP LMII - Bassini X pipe - 3:73 FRRP - Eibach Pro-Kit - Nittos/ Staggerd on 18" GT500 Black chrome wheels - Seq turn - Steeda Short Shifter - Mach 1 grill delete & chin spoiler - Autometer boost & fuel press gauges - Shorty antenna - Smoked head & tail lights - 5K HIDs
FrostByte is offline   Reply With Quote
Old 01-26-2013, 09:31 PM   #15
Nomad8888
1st Gear Member

Nomad8888's Avatar

Join Date: Oct 2012
Vehicle: 2001 Mustang GT
Location: California
Posts: 68
Default

Quote:
Im starting to scare myself. I actually understood that.
Thanks for making me laugh out loud.

Thanks for the great post, Cliffy! Now I have a great roadmap for my 01.
__________________
Those who can make you believe absurdities can make you commit atrocities.
- Voltaire


2001 Mustang GT
Steering Wheel
Exhaust Pipes
Carpet
Round thing on dash
Nomad8888 is offline   Reply With Quote
Old 01-27-2013, 01:58 PM   #16
lizzyfan
Underboss

lizzyfan's Avatar

Join Date: Jan 2006
Vehicle: 98 GT Blumurder
Location: Helaware
Posts: 20,238
Default

Excellent write-up as usual! Thanks Cliffy!!
__________________


540 rwhp 477 tq
Vortech SQ to T-trim upgrade
MHS Stage 2 heads/cams
Tuned by Matt at Performance Evolution
11.055@129 MPH 1.75 60'
lizzyfan is offline   Reply With Quote
Old 01-30-2013, 02:01 PM   #17
V8ORNOTHING
1st Gear Member

V8ORNOTHING's Avatar

Join Date: Jan 2013
Vehicle: 2000 FORD MUSTANG GT
Location: ALBERTA CANADA
Posts: 51
V8ORNOTHING Judds1st
Default

Go with everything listed in the 1st thread on here. I would suggest a good set of underdrive pulleys, they will free up some good power and youll feel a bit more pull in 5th gear, and better fuel millage.
__________________
2000 BRIGHT ATLANTIC BLUE MUSTANG GT
4.6L 2V
FULL BOLTONS BY BBK&PYPES
VEHICLE UNCATTED
VENOM 24LB INJECTORS
WALBRO 255 FUEL PUMP
FORD RACING 4.10 GEARS
KYB QUAD AND REAR SHOCKS
CFN COLD FUSION NITROUS KIT (DRY) 125 SHOT
19X10 CHROME DIABLO WHEELS
SCT X3 91 OCTANE TUNED

TOOK ME 2 YEARS OF MONEY SWEAT&TEARS TO GET HER FROM BONE STOCK TO SOLID NUMBERS AND I DIDN'T INCLUDE THE COSMETIC WORK I'VE PUT IN.

404 RWHP 430 TORQUE
V8ORNOTHING is offline   Reply With Quote
Old 01-30-2013, 04:10 PM   #18
cliffyk
TECH SAVANT


cliffyk's Avatar

Join Date: Dec 2006
Vehicle: 1998 SL500
Location: Saint Augustine, FL
Posts: 10,909
Default

Re: underdrive pulleys, from the "1st post":

"Other mods such as underdrive pulleys, lightweight wheels (all else being equal 18" wheels/tires weigh more than 17"), flywheels and driveshafts can improve acceleration by reducing parasitic load and rotating mass. However if you are the sort that never "floors it" and always shifts at 3k rpm then don't bother; you will never know they are installed. Their benefit is only realised under hard acceleration and mostly in the lower gears." [emphasis added]
__________________
-cliff knight-
SOLD! - 2003 GT, UPR X, FRPP 24lb/h, Magnaflow, PP 70mm TB & plenum,
Delta Force tuned, Steeda UDPs, Ralco flywheel,
RAM HDX clutch, 3.73s, 262 rwHP/305 lb-ft.

New ride (7/1/2013) 1998 Mercedes SL500-5.0L 32V VVT 326/347 HP/tq


Engineering is, at its base, making what you want from what you have.
At its extreme it is making what you want from what you can get.
cliffyk is offline   Reply With Quote
Old 02-01-2013, 09:57 AM   #19
'02gtgarrett
2nd Gear Member


'02gtgarrett's Avatar

Join Date: Oct 2011
Vehicle: 2007 Ford Mustang GT/CS
Location: North Carolina
Posts: 320
Big B1ack Bear charlesgarrettshelton
Default

Cliffyk, so if my mustang was made in april of 2002 do i have the 19 lb or 21 lb. I am assuming that it is the 19 lb.
__________________

Member #131
'02gtgarrett is offline   Reply With Quote
Old 02-01-2013, 10:32 AM   #20
cliffyk
TECH SAVANT


cliffyk's Avatar

Join Date: Dec 2006
Vehicle: 1998 SL500
Location: Saint Augustine, FL
Posts: 10,909
Default

Quote:
Originally Posted by '02gtgarrett View Post
Cliffyk, so if my mustang was made in april of 2002 do i have the 19 lb or 21 lb. I am assuming that it is the 19 lb.
Are they orange or pink (lavender)?

Click the image to open in full size.
__________________
-cliff knight-
SOLD! - 2003 GT, UPR X, FRPP 24lb/h, Magnaflow, PP 70mm TB & plenum,
Delta Force tuned, Steeda UDPs, Ralco flywheel,
RAM HDX clutch, 3.73s, 262 rwHP/305 lb-ft.

New ride (7/1/2013) 1998 Mercedes SL500-5.0L 32V VVT 326/347 HP/tq


Engineering is, at its base, making what you want from what you have.
At its extreme it is making what you want from what you can get.
cliffyk is offline   Reply With Quote
