Old 05-05-2007, 04:53 PM   #1
Join Date: May 2007
Posts: 3

Newbie a little confused

Could someone please help?
I have a 90 mustang gt. I have read eveything I can get my hands on to find out to adjust my valves. Chilton say to bleed down the valve then adjust them. Ford tech say you don't need to bleed the valves.What the deal? Do I need to or not. What is the best way to adjust them.?Chilton has you do it in 3 steps. Some articles say do it1 cylinder at a time. I just put a crane rocker arm stud Converstion kit on. Dose this change the way you adjust them?

Thanks for any help
mustanggtlx is offline   Reply With Quote
Old 05-05-2007, 05:00 PM   #2
2nd Gear Member
thunderjet429's Avatar
Join Date: Mar 2007
Vehicle: 88 LX 5.0
Location: ohio
Posts: 424

if you put a stud conversion on your car the factory positive stop procedure can not be used.

306 Eagle crank, rods, and forged pistons
Edelbrock preformer upper and lower
BBK 70 MM throttle body
Edelbrock preformer RPM heads
Walbro 255lph High Pressure Fuel Pump
Ford Racing 47lb Injectors (EV6)
Ford Motorsport "B" cam
MSD pro billet / MSD 6AL
Converted to mass air
Makes 7.5 pounds of boost
3.73 gears
T5... for now
thunderjet429 is offline   Reply With Quote
Old 05-05-2007, 05:22 PM   #3
6th Gear Member
Join Date: Apr 2007
Vehicle: 67 Mustang Coupe
Location: California
Posts: 10,451

If you converted from pedestal to stud then yeah, you can't use the factory procedure. You'll have to go by what the rocker arm manufacturer says in their instructions
Who cares how much horsepower it has, all that matters is how fast it goes!

Untested 331, lots of suspension, chewing up corners.
67mustang302 is online now   Reply With Quote
Old 05-05-2007, 11:34 PM   #4
Join Date: May 2007
Posts: 3

Thanks guys

But do i still need to bleed down the valves?Crane instruction says do 1 cylinder at a time, turn the adjusting nut 1/2 to 1 turn after you having taken out all the slack (zero lash).
mustanggtlx is offline   Reply With Quote
Old 05-06-2007, 12:13 AM   #5
4th Gear Member
Join Date: Feb 2007
Vehicle: 1993
Location: Long Island, NY
Posts: 1,222

From whatI read....you start at TDC (#1), and you torque bothvalves down to 18lbs......

Then you turn your crank a 1/4 turn.....to the next in the firing order......torque them both down to 18lbs.......

Continue through the firing order until you are done.

I am not sure if this is right, but that is what "they" say. I did that with my a car and it is running GREAT! If anyone else thinks that this is wrong, please let me know.....

93 Notch
278rwhp/306tq (Mustang Dyno)
TrickFlow H/C/I, SCT Tune
BBK Ceramic Shorties/UPR X-Pipe/Flows
3.73s/UPR Control Arms/Eibach ProKits
100% Smog Legal!!
CantStopTheFox... is offline   Reply With Quote
