How much HP does your 289 have?

Reply




Thread Tools Search this Thread
Old 11-27-2009, 05:17 PM   #1
phish
2nd Gear Member

Join Date: May 2009
Vehicle: 65 coupe
Location: GA
Posts: 155
Default How much HP does your 289 have?

just curious as to how much you guys are getting out of a 289. i realize some of you diehards/mechanics are prolly getting a lot and some others are just keeping it more stock. just trying to get some type of average for that engine. and if you have a stroker 289 just mention it.
i have a 289 A code. after it comes back from the shop next week the guy said i should have somewhere in the neighborhood of 300hp.

i have added :
tri Y headers
flowmaster 40 exhaust
voodoo cam
new carb---not exactly sure what it is
new air intake manifold
This ad is not displayed to registered or logged-in members.
Register your free account today and become a member on Mustang Forums!
phish is offline   Reply With Quote
Old 11-27-2009, 07:00 PM   #2
Joe1967
2nd Gear Member

Join Date: Jul 2009
Vehicle: 1967 Mustang
Location: Maryland
Posts: 201
Default

thats not a 300 hp combo

hardly 200 without serious work, or new heads

289's biggest bottle neck is the exhaust ports in the cast heads.
__________________

Proving to be easier said than done
Joe1967 is offline   Reply With Quote
Old 11-27-2009, 07:35 PM   #3
GibMax
2nd Gear Member

GibMax's Avatar

Join Date: Feb 2008
Vehicle: 1966 Ford Mustang Coupe Pony Air
Location: MI
Posts: 240
Default Just give your wife the phone number of your engine builder.

I just gave my wife the phone number of my engine builder. He's looking at a 289 or a 302 for my 66. I'm hoping my wife will call him with a credit card number for xmas.

The engine builder said something about just getting a different cam shaft (difference between a 302 and 289 maybe?).
__________________
Gib

Last edited by GibMax; 11-27-2009 at 07:37 PM.
GibMax is offline   Reply With Quote
Old 11-27-2009, 09:22 PM   #4
Joe1967
2nd Gear Member

Join Date: Jul 2009
Vehicle: 1967 Mustang
Location: Maryland
Posts: 201
Default

302 and 289 cams are virtually the same.... just different ends of the spectrum (if that makes sense) eg, the wild 289 cam is a mild 302 cam.
__________________

Proving to be easier said than done
Joe1967 is offline   Reply With Quote
Old 11-29-2009, 12:02 AM   #5
phish
2nd Gear Member

Join Date: May 2009
Vehicle: 65 coupe
Location: GA
Posts: 155
Default

200 hp after all that work??? they came with 225 stock......i dont see how that is possible. i have never dynoed the car. i have raced many cars and have beat 350z , 98 style mustangs, and other sports cars that have more than 250 hp.....
phish is offline   Reply With Quote
Old 11-29-2009, 08:26 AM   #6
Norm Peterson
6th Gear Member

Norm Peterson's Avatar

Join Date: Feb 2007
Vehicle: 2008 GT Premium
Location: state of confusion
Posts: 6,926
Default

I suspect that different measures of "horsepower" are being spoken here. SAE gross (225, crank), probably SAE net (190-ish), possibly a measurement at the wheels. Comparing just the numbers doesn't help until everybody is speaking the same language.

That said, I'd guess you might be up around where the K-code engine was, assuming a good rebuild and a little fine tuning of the carb and ignition. Call it 275 SAE gross/235 SAE net.

Somebody with better knowledge of what Shelby did to get a claimed 306 might be able to justify another number for you if that sort of work was also done to your engine.

Don't forget that a '65 Mustang is a relative lightweight compared to almost anything recently sold with either a V8 or 250+ horsepower. And while the 289's torque was clearly on the weak side back in the mid-60's (compared to, say, the 327 SBC), it's still going to be higher than what anybody's normally aspirated 2.7- to 3-liter V6 puts out.


Norm
__________________
'08 GT coupe, 5M, suspension unstockish (mine)
'10 Legacy 2.5GT, 6M (hers)
'01 Maxima 20AE, 5M (spare, winter driver)

Gone but not forgotten dep't: '95 Mazda 626, V6/5M; '79 Chevy Malibu, 4M/5M; '87 Maxima, 5M; '72 Ford Pinto, 4M; '64 Dodge V8/3A . . .

Norm Peterson is offline   Reply With Quote
Old 11-29-2009, 02:09 PM   #7
Joe1967
2nd Gear Member

Join Date: Jul 2009
Vehicle: 1967 Mustang
Location: Maryland
Posts: 201
Default

ford's claimed 225 hp stock was more like 190, if that.
HP is a subject often exaggerated, sorta like the concept of why women are so bad with measurements, they've been told 5 inches in 9 inches for years.
__________________

Proving to be easier said than done
Joe1967 is offline   Reply With Quote
Old 11-29-2009, 02:27 PM   #8
racin66coupe
5th Gear Member

racin66coupe's Avatar

Join Date: Dec 2007
Vehicle: 1966 mustang fastback
Location: NH
Posts: 3,480
Default

Quote:
Originally Posted by Joe1967 View Post
sorta like the concept of why women are so bad with measurements, they've been told 5 inches in 9 inches for years.
lolwut?
__________________
Quote:
Originally Posted by britzeee View Post
paul, i love/hate you. always <3
Quote:
Originally Posted by BlueBloodedPony View Post
My IDs used to be FootballnCrabs, but for whatever reason everyone thought I was a homosexual football player that enjoyed spreading his STD around the locker room. Go figure.
racin66coupe is offline   Reply With Quote
Old 11-29-2009, 05:06 PM   #9
longlive289s
3rd Gear Member

Join Date: Oct 2006
Vehicle: 1994, Ford, Cobra
Location: Kirkland, WA
Posts: 934
Default

http://www.youtube.com/watch?v=OeNotjdQ2HM

Rebuilt: 289, suspension (grab-a-trac), c-5 tranny
Upgrades: Weiand Action + Intake maifold, Holley Street Avenger 570cfm, Hooker Comp Headers, Flamethrower Coil and Distributor

at the wheels its 185hp and 240 ft lb tq
__________________


-1994 Cobra: H/C/I, up's, smog del, fluidine cooling, carbon fiber clutch, short throw shifter, 3.55's, racing pan, 04 cobra interior, UPR front end, tubular k and a arms, coilovers, strut tower brace, full length subframe connectors, MAC control arms in the back, fr500's, drag radials, chipped and tuned by Horsepower Ranch. 327rwhp
-1966 Mustang: stripped.....ill get to it when i get some $$$
-2001 chevy pos
longlive289s is offline   Reply With Quote
Old 11-29-2009, 05:10 PM   #10
racin66coupe
5th Gear Member

racin66coupe's Avatar

Join Date: Dec 2007
Vehicle: 1966 mustang fastback
Location: NH
Posts: 3,480
Default

is the short block/cam stock?
__________________
Quote:
Originally Posted by britzeee View Post
paul, i love/hate you. always <3
Quote:
Originally Posted by BlueBloodedPony View Post
My IDs used to be FootballnCrabs, but for whatever reason everyone thought I was a homosexual football player that enjoyed spreading his STD around the locker room. Go figure.
racin66coupe is offline   Reply With Quote
Old 11-29-2009, 07:39 PM   #11
JMD
6th Gear Member

JMD's Avatar

Join Date: Jan 2007
Vehicle: 39 Ford
Location: AR
Posts: 5,468
Default

Ten Thousand and Six....
__________________
Building cars is EASY, building cars right is a mite bit harder.

JMD is offline   Reply With Quote
Old 11-29-2009, 07:53 PM   #12
jonward786
3rd Gear Member

jonward786's Avatar

Join Date: May 2008
Vehicle: 1968 Coupe
Location: San Francisco, CA
Posts: 678
Default

Quote:
Originally Posted by longlive289s View Post
http://www.youtube.com/watch?v=OeNotjdQ2HM

Rebuilt: 289, suspension (grab-a-trac), c-5 tranny
Upgrades: Weiand Action + Intake maifold, Holley Street Avenger 570cfm, Hooker Comp Headers, Flamethrower Coil and Distributor

at the wheels its 185hp and 240 ft lb tq
is that with stock heads or have u done anything to them? (porting, gasket matching ect)
jonward786 is offline   Reply With Quote
Old 12-01-2009, 07:00 PM   #13
JDraper
2nd Gear Member

JDraper's Avatar

Join Date: Sep 2009
Vehicle: 1966 Coupe, 2004 Mach 1
Location: Central PA
Posts: 224
Default

My '66 289 put down 230 rwhp/250 tq corrected (about 290 hp/312 tq) at the flywheel if you assume a 20% drivetrain loss) thru a World Class T-5 transmission with the following setup:

289 Block bored .040" over
Edlebrock Performer 60 cc heads 1.90"/1.60" valves
Edlebrock Performer intake
204°/214° Duration, .448"/.472" Lift cam
Holley Street Avenger 575 cfm carb
Holley Fuel pump/regulator
Crane 1.6 roller rockers
Accel electronic ignition
MAC long tube headers
Summit balancer

A good Tune!!

Here's the Dyno Sheet on it:


Click the image to open in full size.
__________________

'66 Coupe, '04 Mach 1, '05 F-150 SCrew, '08 Focus
And then one day you find, 10 years have got behind you, no one told you when to run, you missed the starting gun...
JDraper is offline   Reply With Quote
Old 12-01-2009, 10:15 PM   #14
THUMPIN455
5th Gear Member

THUMPIN455's Avatar

Join Date: Mar 2005
Vehicle: Too many to list, 30+
Location: Marquette Mi
Posts: 3,566
Default

My 289+178 makes around 700... I dont have any 289s. Just wanted to brag about the **** nasty Pontiac I have..
__________________
POD and Cougar progress pics:
71 Pit of Despair Mustang
67 Cougar

THUMPIN455 is offline   Reply With Quote
Old 12-02-2009, 06:43 AM   #15
Norm Peterson
6th Gear Member

Norm Peterson's Avatar

Join Date: Feb 2007
Vehicle: 2008 GT Premium
Location: state of confusion
Posts: 6,926
Default

Quote:
Originally Posted by JDraper View Post
My '66 289 put down 230 rwhp/250 tq corrected (about 290 hp/312 tq) at the flywheel if you assume a 20% drivetrain loss) thru a World Class T-5 transmission with the following setup:

289 Block bored .040" over
Edlebrock Performer 60 cc heads 1.90"/1.60" valves
Edlebrock Performer intake
204°/214° Duration, .448"/.472" Lift cam
Holley Street Avenger 575 cfm carb
Holley Fuel pump/regulator
Crane 1.6 roller rockers
Accel electronic ignition
MAC long tube headers
Summit balancer
A good Tune!!
Any idea why the curves have that sudden jump in the 5100 - 5300 rpm range? Or maybe I should be asking why does the torque curve have a sag in the midrange?

I'd happily give away a few ponies off the 230.7 HP peak in exchange for filling in that valley in the torque curve between 4000 and 5150. I have an idea what I'd tinker with if it was EFI, but don't really know how to tweak only a specific range with a carb (it's got to be deeper into the carb tuning than just jetting/power valve/accelerator pump tuning; maybe it involves emulsion tubes or air bleeds).


Norm
__________________
'08 GT coupe, 5M, suspension unstockish (mine)
'10 Legacy 2.5GT, 6M (hers)
'01 Maxima 20AE, 5M (spare, winter driver)

Gone but not forgotten dep't: '95 Mazda 626, V6/5M; '79 Chevy Malibu, 4M/5M; '87 Maxima, 5M; '72 Ford Pinto, 4M; '64 Dodge V8/3A . . .


Last edited by Norm Peterson; 12-02-2009 at 06:46 AM.
Norm Peterson is offline   Reply With Quote
Old 12-02-2009, 04:33 PM   #16
JDraper
2nd Gear Member

JDraper's Avatar

Join Date: Sep 2009
Vehicle: 1966 Coupe, 2004 Mach 1
Location: Central PA
Posts: 224
Default

Quote:
Originally Posted by Norm Peterson View Post
Any idea why the curves have that sudden jump in the 5100 - 5300 rpm range? Or maybe I should be asking why does the torque curve have a sag in the midrange?

I'd happily give away a few ponies off the 230.7 HP peak in exchange for filling in that valley in the torque curve between 4000 and 5150. I have an idea what I'd tinker with if it was EFI, but don't really know how to tweak only a specific range with a carb (it's got to be deeper into the carb tuning than just jetting/power valve/accelerator pump tuning; maybe it involves emulsion tubes or air bleeds).


Norm
My tuner and I talked about it, and our conclusion was it might have something to do with the timing. I've got an Accel Billetproof distributor with a combo vacuum/spring advance setup. Unfortunately, at the time the car was on the dyno we didn't have enough different spring combos to work on it further. We did re-jet, change the vacuum secondary opening rate and changed the power pump rate to get it where it is. I had to go down 2 jets on the secondaries, open the secondaries slower and slow down the power pump squirt to fix the a/f ratio issues we had out of the box. The car was dumping fuel and going way rich on initial tip in, then going lean as hell before the secondaries kicked in, then went rich again. When we slowed down the power pump rate, it fixed the initial tip in, but still went lean as the secondaries kicked in and then went rich. We downjetted the secondaries and slowed the opening of the secondaries which got us to a reasonably smooth a/f ratio curve. The drop and bump in the curve was there pretty much all the time, so we're leaning towards the springs in the distributor not expanding linearly.
__________________

'66 Coupe, '04 Mach 1, '05 F-150 SCrew, '08 Focus
And then one day you find, 10 years have got behind you, no one told you when to run, you missed the starting gun...
JDraper is offline   Reply With Quote
Old 12-05-2009, 11:57 PM   #17
phish
2nd Gear Member

Join Date: May 2009
Vehicle: 65 coupe
Location: GA
Posts: 155
Default

hijacked this thread to its death
phish is offline   Reply With Quote
Old 12-06-2009, 07:11 PM   #18
dcohen
4th Gear Member

Join Date: Sep 2005
Vehicle: 1966 Ford Mustang
Location: Salisbury NC
Posts: 1,576
Send a message via AIM to dcohen
Default

i am hoping for 350-360 flywheel hp out of my 289

but thats with performer rpm heads, performer rpm intake, stiff cam, roller rockers, hooker super comp long tubes, and some other odds and ends
__________________
"Dream as if you'll live forever, live as if you'll die today"

James Dean
dcohen is offline   Reply With Quote
Old 12-07-2009, 09:51 AM   #19
phish
2nd Gear Member

Join Date: May 2009
Vehicle: 65 coupe
Location: GA
Posts: 155
Default

with all the 289's out there that all the response i get????? anyone else??
phish is offline   Reply With Quote
Old 12-07-2009, 10:39 AM   #20
Nick.Simonds
4th Gear Member

Nick.Simonds's Avatar

Join Date: Mar 2008
Vehicle: 65 Coupe
Location: Houston, TX
Posts: 1,241
Default

I wouldn't think that a lot of people have taken theirs to the Dyno.
__________________
Nick.Simonds is offline   Reply With Quote
Old 12-07-2009, 10:39 AM
MustangForums
Ford Mustang




Paid Advertisement




Reply

Tags
1965, 1966, 289, 327, 66, action, boost, ccode, coupe, ford, gt, have, horsepower, hp, mustang, sbc, stock, v8, weiand

Thread Tools Search this Thread
Search this Thread:

Advanced Search

Posting Rules
You may not post new threads
You may not post replies
You may not post attachments
You may not edit your posts

BB code is On
Smilies are On
[IMG] code is On
HTML code is Off
Trackbacks are Off
Pingbacks are Off
Refbacks are Off

Forum Jump

Similar Threads
Thread Thread Starter Forum Replies Last Post
How do you no if your a Ricer? rwh129 Mustang News, Concepts, Rumors & Discussion 144 01-25-2012 01:32 PM
What's the cubic inches on a .030 over 289? 65Raven65 Classic Mustangs (Tech) 57 06-22-2007 01:46 PM
Want 400HP out of you're 289?? slickman Classic Mustangs (Tech) 29 08-22-2006 05:08 PM

Advertising

Featured Sponsors
Vendor Directory
New Sponsors
All times are GMT -5. The time now is 09:00 AM.

© Internet Brands, Inc.


This forum is owned and operated by Internet Brands, Inc., a Delaware corporation. It is not authorized or endorsed by the Ford Motor Company and is not affiliated with the Ford Motor Company or its related companies in any way. Ford® is a registered trademark of the Ford Motor Company
Emails Backup
