Old 07-16-2007, 11:07 PM   #1
fastbackmike

Join Date: Jul 2007
Posts: 4
Default 1968 mustang motor mounts for 302

I restored a68 fastback with a j-code 302 ,factory a/c.My problem is my fan blade wont clear my fan shroud?I think I have the wrong motor mounts?Fan &shroud are correct.Is there a special mount for this car?Anyone know where I can the right mounts?


This ad is not displayed to registered or logged-in members.
Register your free account today and become a member on Mustang Forums!
fastbackmike is offline   Reply With Quote
Old 07-16-2007, 11:54 PM   #2
66GTKFB
5th Gear Member

Join Date: Mar 2007
Location:
Posts: 2,623
Default RE: 1968 mustang motor mounts for 302

Motor mounts do not move the motor's position with respect to the radiator. Your words 'restored' mean what - as in what did you do? New fan? New radiator? New shroud? Did you change the fan spacer? And what were the sources of your fan, radiator and shroud?
Jim
66GTKFB is offline   Reply With Quote
Old 07-17-2007, 12:02 AM   #3
mat11089
3rd Gear Member

Join Date: Nov 2006
Location:
Posts: 702
Default RE: 1968 mustang motor mounts for 302

But the do change the height of the engine and the fan would only hit the shroud vertical so yes the motor mounts might very well have everything to do with it.
__________________

66 coupe
late model 302 LT headers 40 series
2.5 inches lower all around
17x7 hopster chrome rims
2200 watts of sound with dual batts,dual amps and cap
mat11089 is offline   Reply With Quote
Old 07-17-2007, 12:08 AM   #4
66GTKFB
5th Gear Member

Join Date: Mar 2007
Location:
Posts: 2,623
Default RE: 1968 mustang motor mounts for 302

And so would a different transmission mount, also called the rear engine mount. There is a lot of important information missing.
Jim
66GTKFB is offline   Reply With Quote
Old 07-17-2007, 06:04 PM   #5
fastbackmike

Join Date: Jul 2007
Posts: 4
Default RE: 1968 mustang motor mounts for 302

Everything on the car is original,fan,fan spacer,radiator,4 speed toploader trans. engine,trans.mount(not sure how that would affect this its a given where thats located?)The parts that I have replaced that would have anything to do with this problem are the motor mounts(bought at local parts store?)and the shroud ,and Im pretty sure its the correct shroud.The fan is hitting the bottom of the shroud,so the engine needs to be raised up 1/4-1/2 inch.Everything was fine until the restore?Thanks for the help!
fastbackmike is offline   Reply With Quote
Old 07-17-2007, 06:31 PM   #6
66GTKFB
5th Gear Member

Join Date: Mar 2007
Location:
Posts: 2,623
Default RE: 1968 mustang motor mounts for 302

I don't think it's your mounts. Take a look at the fanclearance at thetop of shroud. If there's a lot of room, 'adjust' the shroud down, by force if necessary. Is the shroud Ford or aftermarket? I had a fit problem on a 66 when I added the Ford shroud to my new three row radiator. It took some 'adjusting' to clear. Also on a 67 with a 289 I worked on, the first aftermarket one didn't fit but the replacement did.
Jim
66GTKFB is offline   Reply With Quote
Old 07-17-2007, 10:52 PM   #7
fastbackmike

Join Date: Jul 2007
Posts: 4
Default RE: 1968 mustang motor mounts for 302

Well I tried that,didnt help How it mounts on the radiator,and where its cut out around the lower radiator hose wont allow it to go down.I sure dont want to have to replace the motor mounts!
fastbackmike is offline   Reply With Quote
Old 07-17-2007, 10:56 PM   #8
fastbackmike

Join Date: Jul 2007
Posts: 4
Default RE: 1968 mustang motor mounts for 302

My car has the 24" radiator with 4 mounting holes 2 on each side,and the shroud has a cut out to fit around the lower rad. hose theres just not much adjustment?
fastbackmike is offline   Reply With Quote
