750 cfm Demon carb too much?

Reply




Thread Tools Search this Thread
Old 10-14-2008, 11:21 PM   #1
zggill04
2nd Gear Member

Join Date: Jul 2008
Vehicle: 1967 Ford Mustang
Location: NC
Posts: 383
Default 750 cfm Demon carb too much?

Is a 750 cfm Demon carb too much for my mild built 351W? A member of my club is selling one for cheap and I thought I heard people say that 600cfm Holley's take away from some performance on the 351's.
This ad is not displayed to registered or logged-in members.
Register your free account today and become a member on Mustang Forums!
__________________

1967 Mustang Coupe
Brittany blue w/ white stripes
Powered by 351W
zggill04 is offline   Reply With Quote
Old 10-15-2008, 12:03 AM   #2
andrewmp6
6th Gear Member

Join Date: Oct 2006
Location:
Posts: 8,162
Default

depends on a lot like your heads cam intake etc etc.
andrewmp6 is offline   Reply With Quote
Old 10-15-2008, 06:15 AM   #3
fakesnakes
4th Gear Member

fakesnakes's Avatar

Join Date: Sep 2008
Vehicle: Many
Location: Connecticut
Posts: 1,839
Default

If it is truely a mild built 351w and you are using on the street, that carb is a bit too much. A 600 or 650 Holley is a better choice, unless you are racing it regularly.
__________________
Mark

RCR GT40 Mk1
FFR Daytona Coupe (sold, sniff)
1968 GT500KR (clone)
1966 GT350 (clone)
1967 Mustang convertible (unmolested so far)
Hey, my whole life is a fake!

Need some motivation to get that thing started? Try this: http://www.youtube.com/watch?v=WRskJ...e=channel_page
or this:
http://smg.photobucket.com/albums/v6...ndvideo013.flv
fakesnakes is offline   Reply With Quote
Old 10-15-2008, 06:21 AM   #4
zggill04
2nd Gear Member

Join Date: Jul 2008
Vehicle: 1967 Ford Mustang
Location: NC
Posts: 383
Default

Fakesnakes, your one heck of a knowledge base for me and I appreciate it! I'll stick with my 600 Holley then. Now switching gears here for a second. Do you think it would be too much for a 406 Chevy engine? My buddy has one it's got a descent cam in it with some other work, he is going to do some head work here shortly. He has a 625 Demon he was going to put on, I was thinking switch him carbs if the 750 wasn't too big for him.
__________________

1967 Mustang Coupe
Brittany blue w/ white stripes
Powered by 351W
zggill04 is offline   Reply With Quote
Old 10-15-2008, 06:31 AM   #5
kalli
6th Gear Member

Join Date: Oct 2006
Vehicle: 1964, Ford, Mustang
Location: Cork, Ireland
Posts: 6,414
Default

that might be a pretty good idea. you'd love that 625Demon, which will be too tight for him. 750 sounds ok for 408 with decent cam and heads. friend of mine's got a 396 with a 750 and runs good. but don't know what it would be like with a 700cfm ..

it's not experience, that's pure maths talking
__________________
1964 1/2
302ci, Edelbrock RPM heads, xe268h, 650 speed demon, Hooker Long Tube headers and Flowmaster 40s
Quick Performance Racing 9" rear, Moser axles, 3.5:1 trac-loc from FRPP and T5 transmission.
CSRP disc brakes front and FRPP discs back.
http://www.gascc.ie

kalli is offline   Reply With Quote
Old 10-15-2008, 06:39 AM   #6
fakesnakes
4th Gear Member

fakesnakes's Avatar

Join Date: Sep 2008
Vehicle: Many
Location: Connecticut
Posts: 1,839
Default

Glad I can help!

Use this chart, but be aware that your combo is probably only 80 to 90% VE. Not because you have a bad set up, but because that is the normal efficiency of a mild engine. Pay no attention that it is from a Buick site!

http://www.buicks.net/shop/reference/carb_cfm.htm
__________________
Mark

RCR GT40 Mk1
FFR Daytona Coupe (sold, sniff)
1968 GT500KR (clone)
1966 GT350 (clone)
1967 Mustang convertible (unmolested so far)
Hey, my whole life is a fake!

Need some motivation to get that thing started? Try this: http://www.youtube.com/watch?v=WRskJ...e=channel_page
or this:
http://smg.photobucket.com/albums/v6...ndvideo013.flv
fakesnakes is offline   Reply With Quote
Old 10-15-2008, 09:25 AM   #7
kalli
6th Gear Member

Join Date: Oct 2006
Vehicle: 1964, Ford, Mustang
Location: Cork, Ireland
Posts: 6,414
Default

Hiya .. this is getting a cfm discussion again :-)
the link fakesnakes gives matches what about every cfm calculator would suggest.
so for your 351 stock/mild and VE of 75% you should be needing a 380cfm carb at 5000rpm max.
That is a theoretical value of what the engine will need (based on cylindervolume and speed). Fact is that a carb with higher cfm rating will perform better at higher rpms as there is less resistance causing intake manifold vacuum. At wide open throttle there should be none. But if you stay on the lower side of things you will get a much better throttle response. About the same as what people call the straw effect (try drinking water out a straw that is 2" diameter ....)

So that said if you call up holley who manufacture those things they will suggest 650cfm for your engine. If you listen to barry grant then one of the most common problems with carbed applications is overcarbing.

As you have 2 worlds in favour I believe it's a good idea to stay in the middle. For my 289 the 525 demon would have been perfect, but I got that 570 cheap. For your 351 the 600-650 range migt be perfect. A 525cfm might even perform fantastic, but what we all agree on: 750cfm for a mild 351W is wayyyy off :-)

I have no experience on this. What you see above is the summary of reading on this forum for about 2 years worth ... ;-)

in some cases less is sometimes more.
__________________
1964 1/2
302ci, Edelbrock RPM heads, xe268h, 650 speed demon, Hooker Long Tube headers and Flowmaster 40s
Quick Performance Racing 9" rear, Moser axles, 3.5:1 trac-loc from FRPP and T5 transmission.
CSRP disc brakes front and FRPP discs back.
http://www.gascc.ie


Last edited by kalli; 10-15-2008 at 09:32 AM.
kalli is offline   Reply With Quote
Old 10-15-2008, 09:44 AM   #8
zggill04
2nd Gear Member

Join Date: Jul 2008
Vehicle: 1967 Ford Mustang
Location: NC
Posts: 383
Default

All good info.

Now this problem leaks over to my buddies car too. It's a 1970 Monte Carlo, and he has the 400 sbc, yes small block, not big block, pushed to a 408. He's been pushing carbs for a little bit, but sticks to around the 600cfm. At the track he tends to brake up in the upper end, and I've always thought it was just starving up there. Would a 700cfm be over carbed for his application? He's got a little bit more build with a final touch of aluminum heads coming sometime in the near future. But he has forged internals, dome pistons, cam, blah blah blah. What do you think trading the 700 to him for the 625 demon? I'm not looking to screw the pooch on this one, he's like a brother to me.
__________________

1967 Mustang Coupe
Brittany blue w/ white stripes
Powered by 351W
zggill04 is offline   Reply With Quote
Old 10-15-2008, 10:26 AM   #9
retro77
2nd Gear Member

Join Date: Feb 2008
Vehicle: 1967 Ford Mustang
Location: CA
Posts: 317
Default

I'd say have your buddy join one of the many Chevy forums out there to get a real educated answer.
retro77 is offline   Reply With Quote
Old 10-15-2008, 10:33 AM   #10
urban_cowboy
5th Gear Member

urban_cowboy's Avatar

Join Date: Apr 2007
Vehicle: '69 Mustang Mach1
Location: Texas Hill Country
Posts: 2,100
Default

Short answer is yes unless you are using a turbo or blower. If naturaly aspirated, your 351CID need a 650cfm, no more.

On a 400, I would say 700 possibly a 750. I have a 750 on my 383 and it is really too much. I have atomization problems that I could probably cure with a 700. Make and brand don't matter when it comes to carb sizes.

The only thing that matters is how much air is entering the intake and how fast. You want the aire to be as fast a possible which requires, believe it or not, a smaller opening. A big opening has plenty of potential but no velocity. When you over carb, you loose air velocity which causes the carb to not atomize the fuel into the air. You get big drops of fuel entering the intake. Mist burns, drops do not! Thus overcarbing is bad. The trick is to have the smallest hole, or venturi, without creatating a restirction where you engine cannot pull enough air in. The amount of air required by a given engine is based on CID (cubic inch displacment) and VE (volumetric efficiency). CID is easy. You have a 351 and your friend has a 400. The hard part is the VE. That is determined by your intake, heads, and cam. Unless you have a NHRA ProStock car, you do not have more than 100%VE without using power adders. Also the VE of an engine is going to change throughout the rpm band. Most engines max out at about 88-90%. Below is a link to a carb calculator that should help get you in the ball park.
http://www.csgnetwork.com/cfmcalc.html

One other thing. Have you ever wondered why the ProStock NHRA guys rev their motors in neutral? It is "clear" them out. They are overcarbed at low rpm due to low VE at low rpm (high power band) so wet fuel is entering the cylinders which washes the cylinders down and does not burn well. They rev the motor up after idling a while to blow that wet stuff out and prevent floading the engine. At high rpms, the carb works the way it should because their VE comes way up and the engine is happy.

Over carbing is bad, but in race cars you be over carbed at low rpms so you have it right in your racing band. On street cars, we typically do not have the problem.
__________________

"Yeah, were runnin a little bit hot tonight. I can barely see the road from the heat comin' off of it." Van Halen
12.20sec 1/4mi @ 115.50mph
http://www.hardtohandleracing.com

Last edited by urban_cowboy; 10-15-2008 at 10:55 AM.
urban_cowboy is offline   Reply With Quote
Old 10-15-2008, 10:35 AM   #11
SalikDDD
3rd Gear Member

Join Date: Oct 2007
Location: Florida
Posts: 671
Default

i run a 670 on my 331 stroker, but i'm switching to a 750 since it will be drag racing more often then daily driving, with the 670 it performs excellently. i put the 600 on it for giggles and it was a dog, but for the 289 it was fine.

i'd say it's all in what you plan to do with it, the cam etc. so don't be afraid to go bigger if you've got the motor to back it up. as for the chevrolet, we've got a mild 350 in a K10 with a 750 on it and it runs great.
__________________
1998 Mustang GT - 1987 Mustang LX RIP - 1967 Mustang Coupe
SalikDDD is offline   Reply With Quote
Old 10-15-2008, 11:00 AM   #12
urban_cowboy
5th Gear Member

urban_cowboy's Avatar

Join Date: Apr 2007
Vehicle: '69 Mustang Mach1
Location: Texas Hill Country
Posts: 2,100
Default

Be afraid to go bigger, unless you know what you are doing. There is no reason to put more capacity of air flow on a engine if the bore, stroke, heads, and cam cannot make use of it. All you are doing by going bigger is cause tuning problems that may can never be fixed. CID and VE rule what you need. Most people have no idea what their VE is. My 383 maxes out at about 94% based on dyno numbers, but most motors are way below that. Like I said above, plane janers may not get above 90%.
__________________

"Yeah, were runnin a little bit hot tonight. I can barely see the road from the heat comin' off of it." Van Halen
12.20sec 1/4mi @ 115.50mph
http://www.hardtohandleracing.com
urban_cowboy is offline   Reply With Quote
Old 10-15-2008, 01:21 PM   #13
zggill04
2nd Gear Member

Join Date: Jul 2008
Vehicle: 1967 Ford Mustang
Location: NC
Posts: 383
Default

Yeah, I'm not going to go with the 700. Just trying to figure out if the 408 will work better with it then a 625. Like I said, he races frequently, but was breaking up up top, so I'm thinking he'll be good with it. Though he said his car ran like a dog with the 650 double pumper. But that's a different carb altogether.
__________________

1967 Mustang Coupe
Brittany blue w/ white stripes
Powered by 351W
zggill04 is offline   Reply With Quote
Old 10-15-2008, 03:11 PM   #14
JMD
6th Gear Member

JMD's Avatar

Join Date: Jan 2007
Vehicle: 39 Ford
Location: AR
Posts: 5,468
Default

750 Mighty Demon works great on 66JamesStang's 408W... It is for sure not too much carb, nor too little...

I say the trade thing should work out pretty well.

Oh yea, and also, my other son is useing a 750 Mighty Demon on his strong 350 Chevy SB (aprox 450 HP), it works great, contrary to popular opinion, it is NOT too big for this engine...

In this instance, reality trumps theory.....
__________________
Building cars is EASY, building cars right is a mite bit harder.


Last edited by JMD; 10-15-2008 at 03:29 PM. Reason: 350 SB info added.
JMD is offline   Reply With Quote
Old 10-15-2008, 03:30 PM   #15
zggill04
2nd Gear Member

Join Date: Jul 2008
Vehicle: 1967 Ford Mustang
Location: NC
Posts: 383
Default

Good info JMD. I figured he would be pretty good with it. He's sitting probably around the same hp as the 408, maybe a little less. I'm going to talk to him tonight and see what he says.
__________________

1967 Mustang Coupe
Brittany blue w/ white stripes
Powered by 351W
zggill04 is offline   Reply With Quote
Old 10-15-2008, 07:05 PM   #16
MonsterBilly
4th Gear Member

MonsterBilly's Avatar

Join Date: Aug 2008
Vehicle: 66 coupe
Location: Goodyear, AZ
Posts: 1,469
Default

Here is my 2 CENTS. i HAVE A 289 PORTED AND POLISHED WITH INTAKE. I AM RUNNING A STREET AVANGER 670 CFM. MY CAR RUNS GREAT. I WAS TOLD BY EVERYONE ON HERE IT WAS TOO BIG. I CANT BELIEVE HOW GREAT IT RUNS. I HAVE YET TO TUNE IT BUT EVEN WITHOUT TUNE I DONT THINK IT COULD BE BETTER.

I SAY BUY IT AND TRY IT. IF IT IS THAT CHEAP.
MonsterBilly is offline   Reply With Quote
Old 10-16-2008, 06:53 AM   #17
67 evil eleanor
5th Gear Member

Join Date: Nov 2006
Location:
Posts: 2,106
Default

My 428 has a 735. My Boss 302 has a 650 and it shuts down at 8200, with some room left. Based on the charts and past experiencs, I would say the 650 will be more than enough and carry you up to 9000 withont fizzling out. Everything was over carbed in the old days even with the higher octane fuels. If you plan on spinning 10,000 RPM, then the 750 will be fine. Don't forget about re-jetting if you decide on that BIG carb. A wideband would be very helpful when you get into it.
__________________
[IMG][/IMG] Eat Rice and be Healthy!!!
67 evil eleanor is offline   Reply With Quote
Old 10-16-2008, 07:35 AM   #18
kalli
6th Gear Member

Join Date: Oct 2006
Vehicle: 1964, Ford, Mustang
Location: Cork, Ireland
Posts: 6,414
Default

Quote:
Originally Posted by 67 evil eleanor View Post
My Boss 302 has a 650 and it shuts down at 8200
i would love to hear a boss 302 spin to 8000. that must me a monster of a sound ...
__________________
1964 1/2
302ci, Edelbrock RPM heads, xe268h, 650 speed demon, Hooker Long Tube headers and Flowmaster 40s
Quick Performance Racing 9" rear, Moser axles, 3.5:1 trac-loc from FRPP and T5 transmission.
CSRP disc brakes front and FRPP discs back.
http://www.gascc.ie

kalli is offline   Reply With Quote
Old 10-16-2008, 11:44 AM   #19
zggill04
2nd Gear Member

Join Date: Jul 2008
Vehicle: 1967 Ford Mustang
Location: NC
Posts: 383
Default

I tried to call my buddy last night but he was busy. I'm going to try him again today. But I'm either going to keep my 600 Holley or trade him for the 625 Demon.
__________________

1967 Mustang Coupe
Brittany blue w/ white stripes
Powered by 351W
zggill04 is offline   Reply With Quote
Old 10-16-2008, 06:50 PM   #20
htwheelz67
3rd Gear Member

Join Date: Aug 2007
Location:
Posts: 572
Default

the 625 road demon is great for mild 351w's, a 750 will be a bit big unless its an annular model, the thing about demon carbs is they flow way more than their rating, a 750 demon can flow about 850-875 cfm, even the 625 can flow 725-750 cfm. I run a mighty demon 750 annular on my 408 and it runs better than my custom 950hp holley.
__________________
67 vert, 408 stroker 205cc TW heads, CI cust hyd roller,Dougs 1 3/4 try y's, global west neg roll,lentech aod...etc etc etc
htwheelz67 is offline   Reply With Quote
