Old 12-14-2011, 02:58 PM   #1
fergal289


fergal289's Avatar

Join Date: Nov 2008
Vehicle: 1967
Location: UK
Posts: 38
Default Difference between 289 and a 351 windsor

Can anyone give me a simple easy to spot difference between a 289 and a 351 Windsor.

I'm in the UK, and I'm just trying to ID the engine in my 68 Fastback. A picture would be great.

Thanks....
This ad is not displayed to registered or logged-in members.
Register your free account today and become a member on Mustang Forums!
fergal289 is offline   Reply With Quote
Old 12-14-2011, 05:11 PM   #2
rockinstephen

Join Date: Oct 2011
Vehicle: 1992 Mustang LX Convertible
Location: Maine/Florida
Posts: 37
N/A N/A N/A N/A N/A
Default

That's a good question. Sorry, I can't answer it. But while we're on the subject, what's the difference between a 351 Windsor and a 351 Cleveland?
rockinstephen is offline   Reply With Quote
Old 12-14-2011, 05:13 PM   #3
jesse1125
2nd Gear Member

jesse1125's Avatar

Join Date: Feb 2010
Vehicle: 2014 v6
Location: Oklahoma
Posts: 150
Default

Windsor is a small block, Cleveland is a big block
jesse1125 is offline   Reply With Quote
Old 12-14-2011, 06:06 PM   #4
JMD
6th Gear Member

JMD's Avatar

Join Date: Jan 2007
Vehicle: 39 Ford
Location: AR
Posts: 5,468
Default

351 - Has about 1" more block above timing cover...

Click the image to open in full size.

302 - Shorter deck, deck about even with timing cover

Click the image to open in full size.

These are essentially the same engine design, but the 351 block has about an extra inch or so in cylinder length to accommodate the longer stroke of the 351.
__________________
Building cars is EASY, building cars right is a mite bit harder.


Last edited by JMD; 12-14-2011 at 07:41 PM.
JMD is offline   Reply With Quote
Old 12-14-2011, 06:07 PM   #5
ponyboychris


ponyboychris's Avatar

Join Date: Aug 2011
Vehicle: 1967 Ford Mustang Fastback
Location: Colorado
Posts: 20
Default

At first glance, 289/302's look very similar to the 351 Windsors. The main difference is the 351 Windsors engines are wider at the intake manifold because of the increased deck height of the block (about 1.3" taller). I always determined the difference by looking at the firing order - 289/302W are (1-5-4-2-6-3-7-8) and the 351W is (1-3-7-2-6-5-4-8).
__________________
1967 Mustang Fastback
ponyboychris is offline   Reply With Quote
Old 12-14-2011, 06:22 PM   #6
frdnut
2nd Gear Member

frdnut's Avatar

Join Date: Nov 2010
Vehicle: 68 mustang
Location: Ontario
Posts: 492
Default

The easiest way to tell the difference is to look for the two vertical ribs,one on each side of the distributor that run from the intake mounting surface to the timing cover..If it has them it is a 351..Look at the first picture that JMD posted as it shows them very clearly
__________________

68 J code 408W topoader with 4:11 detroit locker 11.82 @120.85
frdnut is offline   Reply With Quote
Old 12-14-2011, 07:40 PM   #7
2+2GT
6th Gear Member

Join Date: May 2009
Vehicle: 66 Mustang 2+2GT
Location: PA
Posts: 5,221
Default

Quote:
Originally Posted by jesse1125 View Post
Windsor is a small block, Cleveland is a big block
The 351C is also a smallblock, of the Cleveland family. Uses the same motor mounts, flywheel, and bellhousing as the 351W, in fact Cleveland heads can be installed on the 289/302/351W with a little customizing. In fact, the 351C 4V heads orignally appeared on the BOSS 302. The overall dimensions of the W and C are nearly identical, and they have the same bore and stroke.
__________________
Amateur restorer. (Well, once in a while I have been paid for it)
2+2GT is offline   Reply With Quote
Old 12-14-2011, 11:29 PM   #8
musnicki
3rd Gear Member


musnicki's Avatar

Join Date: Dec 2007
Vehicle: 1967, Ford, Mustang Fastback
Location: Bangkok, Thailand
Posts: 933
James Musnicki
Send a message via AIM to musnicki
Default

I learn something new every day when I come to this forum. There are some very smart people here.

James
__________________


Musnicki
musnicki is offline   Reply With Quote
Old 12-15-2011, 02:31 PM   #9
fergal289


fergal289's Avatar

Join Date: Nov 2008
Vehicle: 1967
Location: UK
Posts: 38
Default thanks

Thank you Chaps!

I think you have simplified that for me. Appreciate your input.
fergal289 is offline   Reply With Quote
Old 12-15-2011, 02:55 PM   #10
JMD
6th Gear Member

JMD's Avatar

Join Date: Jan 2007
Vehicle: 39 Ford
Location: AR
Posts: 5,468
Default

Quote:
Originally Posted by ponyboychris View Post
At first glance, 289/302's look very similar to the 351 Windsors. The main difference is the 351 Windsors engines are wider at the intake manifold because of the increased deck height of the block (about 1.3" taller). I always determined the difference by looking at the firing order - 289/302W are (1-5-4-2-6-3-7-8) and the 351W is (1-3-7-2-6-5-4-8).
The firing order difference doesn't always work, the later 5.0 HO motors used the 351 order.


289
1-5-4-2-6-3-7-8

302 (Pre-82)

1-5-4-2-6-3-7-8

5.0

1-5-4-2-6-3-7-8

5.0 HO

1-3-7-2-6-5-4-8

5.0 Truck

1-5-4-2-6-3-7-8

351

1-3-7-2-6-5-4-8
__________________
Building cars is EASY, building cars right is a mite bit harder.


Last edited by JMD; 12-15-2011 at 03:02 PM.
JMD is offline   Reply With Quote
