Default how to install GT front bumper?

i can't find it anywhere, the "how-to" no longer has pictures.
This ad is not displayed to registered or logged-in members.
Register your free account today and become a member on Mustang Forums!
__________________

2005 Ford MUSTANG 4.0 V6
geckoman1220 is offline   Reply With Quote
Old 03-12-2010, 02:33 AM   #2
2005Redfire6
6th Gear Member

Join Date: Jul 2008
Vehicle: 2005 Mustang
Location: Acworth, GA
Posts: 12,234
Default

Its simple. You remove your radiator cover and the two 10mm boLts on the top of your bumper next to your headlights. Then you remove the front part of the fenderwells and there is two nuts on each side you take off. Then you just bolt up the GT bumper. That's it!
2005Redfire6 is offline   Reply With Quote
Old 03-13-2010, 10:20 AM   #3
157dB
Cut & Paste Expert

157dB's Avatar

Join Date: May 2007
Vehicle: 2007 Pony Package
Location: NW Arkansas
Posts: 13,312
Default

It not that simple 05 mustang mark III ....


Do you have the front inner GT fender well liners and the GT 'stone deflector'?
How bout the GT or aftermarket GT grill for the bumper?
__________________
NON PUMKIN JACKER
http://www.mustangforums.com/forum/5...-this-car.html
Quote:
Originally Posted by chronos View Post
You and that darn manual! If you like it so much, maybe you should marry it!
157dB is offline   Reply With Quote
Old 03-13-2010, 04:11 PM   #4
atldave
2nd Gear Member

atldave's Avatar

Join Date: Oct 2008
Vehicle: 2008, Ford, Mustang Convertible V-6
Location: Georgia
Posts: 356
Default

I have a new GT front bumper and grill from Newtakeoff sitting in a box in the garage until I get the spare parts together and have time to do the install. Could I ask which of the spare parts are really essential? My dealer wants about $45 each for the stone deflector and each of the splash guards. (So, about $140 just for these parts.) Do I need to replace these? Also, do I need a new foam isolator (about $14), screws, and inserts (about another $20)? I don't want to waste money, but I also don't want to get the job half finished and then find I need to order missing parts. Thanks!
__________________


2008 V6 auto convertible. Go: GT duals/custom H pipe, front and rear GT sways/poly bushings, Brenspeed tune and CAI. Show: Blackout panel, painted mirror caps, 17" Bullitt rims and Pirelli Pzeros, GT front bumper.
atldave is offline   Reply With Quote
Old 03-13-2010, 05:13 PM   #5
Rollingstone
1st Gear Member

Join Date: Mar 2008
Vehicle: 12 GT 5.0
Location: Tucson, Arizona
Posts: 80
Default

bump......

I also have a GT front bumper sitting at home and would like to know what parts are absolutely necessary to do the install. The less I have to spend on these parts the better





Quote:
Originally Posted by atldave View Post
I have a new GT front bumper and grill from Newtakeoff sitting in a box in the garage until I get the spare parts together and have time to do the install. Could I ask which of the spare parts are really essential? My dealer wants about $45 each for the stone deflector and each of the splash guards. (So, about $140 just for these parts.) Do I need to replace these? Also, do I need a new foam isolator (about $14), screws, and inserts (about another $20)? I don't want to waste money, but I also don't want to get the job half finished and then find I need to order missing parts. Thanks!
Rollingstone is offline   Reply With Quote
Old 03-13-2010, 05:59 PM   #6
157dB
Cut & Paste Expert

157dB's Avatar

Join Date: May 2007
Vehicle: 2007 Pony Package
Location: NW Arkansas
Posts: 13,312
Default

The foam can be trimmed and the other items can be outsourced.
MustangsUnlimited has the stone deflector for cheaper.
If you want the GT bumper cover to fit right and for the engine to
cool properly at speed, you need these items...

GT - fender liners 5R3Z*16102*BA (right) 5R3Z*16103*BA (left)
GT - radiator deflector 5R3Z*17626*BA
__________________
NON PUMKIN JACKER
http://www.mustangforums.com/forum/5...-this-car.html
Quote:
Originally Posted by chronos View Post
You and that darn manual! If you like it so much, maybe you should marry it!

Last edited by 157dB; 03-13-2010 at 06:13 PM.
157dB is offline   Reply With Quote
Old 03-13-2010, 06:30 PM   #7
atldave
2nd Gear Member

atldave's Avatar

Join Date: Oct 2008
Vehicle: 2008, Ford, Mustang Convertible V-6
Location: Georgia
Posts: 356
Default

Quote:
Originally Posted by 157db View Post
The foam can be trimmed and the other items can be outsourced.
MustangsUnlimited has the stone deflector for cheaper.
If you want the GT bumper cover to fit right and for the engine to
cool properly at speed, you need these items...

GT - fender liners 5R3Z*16102*BA (right) 5R3Z*16103*BA (left)
GT - radiator deflector 5R3Z*17626*BA
Thanks for this quick response. Just what I needed! I'll check MustangsUnlimited for the deflector. Just like every project I've done on my car... it's always more expensive and time-consuming than you figured by the time you get a job completely finished.
__________________


2008 V6 auto convertible. Go: GT duals/custom H pipe, front and rear GT sways/poly bushings, Brenspeed tune and CAI. Show: Blackout panel, painted mirror caps, 17" Bullitt rims and Pirelli Pzeros, GT front bumper.
atldave is offline   Reply With Quote
Old 03-13-2010, 07:28 PM   #8
Joshspony
3rd Gear Member

Joshspony's Avatar

Join Date: Apr 2009
Vehicle: 2006 Mustang Coupe PP
Location: WI
Posts: 771
Default

Quote:
Originally Posted by 157db View Post
The foam can be trimmed and the other items can be outsourced.
MustangsUnlimited has the stone deflector for cheaper.
If you want the GT bumper cover to fit right and for the engine to
cool properly at speed, you need these items...

GT - fender liners 5R3Z*16102*BA (right) 5R3Z*16103*BA (left)
GT - radiator deflector 5R3Z*17626*BA
I did this last summer. As 157 said, both fender liners and radiator deflector are whats needed. The bolts and screws can be picked up at a local hardware for cheaper, I used stainless steel. There are the plastic push fasteners that hold the liners in place, not a bad idea to get a few of those though. They break/strip easily, and if your not careful you'll need them.

Good luck and let us know if you have any other questions.
__________________
Show Mods: Tint 35% on front 20% on 1/4s and rear, shorty billet antenna, Gt front and rear bumpers, CDC GT classic chin spoiler (black textured), clear front turn signals, lower grille inserts

Go Mods: Xcharger Xtreme #201, Borla dual exhaust with X pipe & 4" tips, C&L cai w/ Bama tunes, 8.8" w/ 3.73s and Tlok, strut tower brace, lower A-frame brace

Need more mod money!
Joshspony is offline   Reply With Quote
Old 11-03-2013, 12:28 PM   #9
Topless Stang
2nd Gear Member

Topless Stang's Avatar

Join Date: Feb 2009
Vehicle: 2006 Ford Mustang V6 Convertible
Location: FL
Posts: 419
Default

Quote:
Originally Posted by Joshspony View Post
I did this last summer. As 157 said, both fender liners and radiator deflector are whats needed. The bolts and screws can be picked up at a local hardware for cheaper, I used stainless steel. There are the plastic push fasteners that hold the liners in place, not a bad idea to get a few of those though. They break/strip easily, and if your not careful you'll need them.

Good luck and let us know if you have any other questions.
What bolts and screws are needed for the deflector? Also how much do I need to trim off the existing isolator? I'm swapping in a GT style bumper this weekend...
__________________
V6 Perf White 'Vert

Appearance: Roush Spoiler, 20" Shelby Redlines, Gen5 Tails

Mechanical: Dimpled & Slotted,Livewires,ProCharger w/3.40 pulley,Mac LTs,Prochamber,8.8" w/3.73s,J&M Adj Panhard & UCA,J&M LCAs,Koni Yellows w/Vogtlands, Takeoff Sways & Mufflers

Audio: Kenwood DNX9990HD,Hertz Hi Energy Speakers,CVT 8s,TypeR 12s, RF Power 1000 5ch

Topless Stang is offline   Reply With Quote
Old 11-30-2013, 11:22 AM   #10
157dB
Cut & Paste Expert

157dB's Avatar

Join Date: May 2007
Vehicle: 2007 Pony Package
Location: NW Arkansas
Posts: 13,312
Default

http://mustangforums.com/forum/v6-s1...r-upgrade.html
http://mustangforums.com/forum/4-0l-...per-on-v6.html
http://mustangforums.com/forum/v6-s1...-now-what.html
http://mustangforums.com/forum/v6-s1...e-in-a-v6.html
http://mustangforums.com/forum/v6-s1...d-problem.html
http://mustangforums.com/forum/4-0l-...mper-help.html
