Old 10-25-2007, 01:56 PM   #1
Projectquick
5th Gear Member


Projectquick's Avatar

Join Date: Aug 2007
Vehicle: 86 LX
Location: Jersey
Posts: 2,445
Default Gears for a Mach 1

I have been doing alot of reasearch on Mach 1s since I am really interested in buying one. I have searched here, I have asked people who own them, and even asked on other forums. Why do you guys suggest going with 4.10s or 4.30s? I know that the 4 valves are rev happy but it just seems that 4.30 would be too steep for highway driving. Drag racing would be cool to do in a Mach so I guess thats where the 4.30s would really help, but say you want to top the car out on the highway or some abandoned air field, wouldn't 4.30s seriously limit the top end?
This ad is not displayed to registered or logged-in members.
Register your free account today and become a member on Mustang Forums!
__________________
86 LX
bolt on cammed 5.0 with 125 shot.
351w build starting
Projectquick is offline   Reply With Quote
Old 10-25-2007, 02:33 PM   #2
jchittick
3rd Gear Member

Join Date: Mar 2005
Location: Memphis
Posts: 626
Default RE: Gears for a Mach 1

How fast do you go on the highway, seriously? I don't think you will run out of top end. Mach1 4R70W ratios as follows
2.84
1.55
1.00
0.70 (OD)


Manual
.62 ratio, 80mph, at X.XX:1 rear gear ratio

3.55 = 2304 rpm
3.73 = 2421 rpm
4.10 = 2661 rpm
4.30 = 2791 rpm
4.56 = 2960 rpm

top speed w/ 3.55s, 5th gear @ 6798 rpm = 236 mph
top speed w/ 3.73s, 5th gear @ 6780 rpm = 224 mph
top speed w/ 4.10s, 5th gear @ 6787 rpm = 204 mph
top speed w/ 4.30s, 5th gear @ 6769 rpm = 194 mph
top speed w/ 4.56s, 5th gear @ 6771 rpm = 183 mph

Auto
.70 ratio, 80mph, at X.XX:1 rear gear ratio

3.55 = 2602 rpm
3.73 = 2733 rpm
4.10 = 3005 rpm
4.30 = 3151 rpm
4.56 = 3342 rpm

top speed w/ 3.55, @ 5789 rpm = 178 mph
top speed w/ 3.73, @ 5775 rpm = 169 mph
top speed w/ 4.10, @ 5784 rpm = 154 mph
top speed w/ 4.30, @ 5791 rpm = 147 mph
top speed w/ 4.56, @ 5765 rpm = 138 mph
__________________

2004 Black Mach 1 5sp, IUP Born 1/9/2004
JLT RAI, SCT X3, MGW, MAC Off Road H, flows
jchittick is offline   Reply With Quote
Old 10-25-2007, 02:39 PM   #3
Projectquick
5th Gear Member


Projectquick's Avatar

Join Date: Aug 2007
Vehicle: 86 LX
Location: Jersey
Posts: 2,445
Default RE: Gears for a Mach 1

Manual
.62 ratio, 80mph, at X.XX:1 rear gear ratio

3.55 = 2304 rpm
3.73 = 2421 rpm
4.10 = 2661 rpm
4.30 = 2791 rpm
4.56 = 2960 rpm
I did not know all that, it really helps. So according to this if I run 4.30s and am doing 80mph I will only be turning 2800rpms? Does this sound right to the people running 4.30s?
__________________
86 LX
bolt on cammed 5.0 with 125 shot.
351w build starting
Projectquick is offline   Reply With Quote
Old 10-25-2007, 02:41 PM   #4
Leprechon777

Join Date: Oct 2007
Location:
Posts: 4
Default RE: Gears for a Mach 1

I am going through the same decision as you. People said that you loose too much top speed with the 4.30's. I was bored one day and put this info together:

http://www.mach1registry.org/forums/...ad.php?t=70870

Its helpful for seeing RPM to speed with different gearing. Going 70 mph in 5th gear with stock gearing you are at 2016 rpm, with 4.30 you rev at 2442. So your gainined about 400 rpm, which isnt going to be terrible on gas mileage. As far as loosing top speed, you have nothing to worry about when getting 4.30's. The way the transmission is set up, and with stock gearing, you can technically get to 236 mph ( a stock mach could not do that). With 4.30 gearing, your top speed is 194, which can be possible for a mach and having the higher gearing makes it more possible. The only reason you would not want to get 4.30's over 4.10's would be gas milage. But with 4.10's you RPM at 70 mph is 2329, just 100 less then 4.30's.
__________________
2004 Ford Mustang Mach I
40th Year Anniv. Color Charcoal w/ Black Leather
- 75k/6yr warranty (62k, 2.5 years left!)
- Bassani High Flow Catted X Pipe
- Bassani Catback
- C&L 85mm MAF/Cold Air Kit
- MGW Short Shifter Orange
Only 13,400 mil
Leprechon777 is offline   Reply With Quote
Old 10-25-2007, 02:43 PM   #5
Projectquick
5th Gear Member


Projectquick's Avatar

Join Date: Aug 2007
Vehicle: 86 LX
Location: Jersey
Posts: 2,445
Default RE: Gears for a Mach 1

But turning 2800 rpms in a mustang is like nothing. My friend has a 94 with a 5.0 and apparently stock gearing but is turning 4500 rpms at 100 mph. To be fair he is an ******* and will not pop off the diff cover to see for sure.
__________________
86 LX
bolt on cammed 5.0 with 125 shot.
351w build starting
Projectquick is offline   Reply With Quote
Old 10-25-2007, 03:12 PM   #6
5speedstang
4th Gear Member

Join Date: Jun 2006
Location: macomb
Posts: 1,777
Default RE: Gears for a Mach 1

Quote:
ORIGINAL: Projectquick

But turning 2800 rpms in a mustang is like nothing. My friend has a 94 with a 5.0 and apparently stock gearing but is turning 4500 rpms at 100 mph. To be fair he is an ******* and will not pop off the diff cover to see for sure.
you dont need to take the diff cover off to see what size gears are in there .just jack up the rear mark both tires at the bottom and mark the drive shaft at the bottom. turn the tires 1 whole turn so both lines are back at the bottom and count how many times the driveshaft turns. if it turns 4 times you have 4.10s if it turns 4 1/4 times you have 4.30s if it turns 4 1/2 times you have 4.56s very east drive way test.
__________________
03 gt best 12.9 on slicks stock gears no tune - sold bc lost to my friends 01 cobra
04 mach 1 full bolt on best 12.3 before headers and pullys- sold bc 2 dr tickets
5speedstang is offline   Reply With Quote
Old 10-25-2007, 03:31 PM   #7
xx9gt6xx
4th Gear Member

Join Date: Nov 2005
Vehicle: 1999 Ford Mustang GT
Location: Michigan
Posts: 1,235
Send a message via AIM to xx9gt6xx
Default RE: Gears for a Mach 1

I say 4:10's just to be safe if your doing highway driving...
__________________
..Modded 1996 Ford Mustang GT.. SOLD!!
..Modded 2001 Ford Mustang SVT Cobra.. SOLD!!

Now..

..Modded 2003 Ford Mustang SVT Cobra, Anniversary Edition..
xx9gt6xx is offline   Reply With Quote
Old 10-25-2007, 09:17 PM   #8
Projectquick
5th Gear Member


Projectquick's Avatar

Join Date: Aug 2007
Vehicle: 86 LX
Location: Jersey
Posts: 2,445
Default RE: Gears for a Mach 1

Well the way it looks I should be fine with the 4.30s. I mean I don't drive 100mph everywhere on the highway, its just nice to know I can if I really wanted.
__________________
86 LX
bolt on cammed 5.0 with 125 shot.
351w build starting
Projectquick is offline   Reply With Quote
Old 10-25-2007, 09:18 PM   #9
01snake
5th Gear Member


Join Date: May 2007
Vehicle: 2001 ford cobra
Location: Michigan
Posts: 2,795
Default RE: Gears for a Mach 1

4.30's

im doing that with 150 shot

__________________

2001 True Blue Cobra
01snake is offline   Reply With Quote
Old 10-25-2007, 09:26 PM   #10
Projectquick
5th Gear Member


Projectquick's Avatar

Join Date: Aug 2007
Vehicle: 86 LX
Location: Jersey
Posts: 2,445
Default RE: Gears for a Mach 1

Do you drive your car more at the track or on the street? 4.30s and 150 shot will make that car FLY.
__________________
86 LX
bolt on cammed 5.0 with 125 shot.
351w build starting
Projectquick is offline   Reply With Quote
