Default HEADERS

ARE THESE ANY GOOD?

Manzo Manifold Exhaust Header Fits Mustang 05-10 4.0L V6 245 CID SOHC Non GT

Old Mar 4, 2020 | 12:05 AM
  #2
Dino Dino Bambino's Avatar
Dino Dino Bambino
4th Gear Member

Joined: Oct 2014
Posts: 1,620
From: Cyprus (EU)
Default

They look well made and are 304 stainless steel. The question is how well they fit and there's only one way to find out.
Don't expect more than a 5hp gain. Shorties tend to add more torque at lower rpm and improve the sound compared to the stock manifolds.
Old Mar 4, 2020 | 05:53 AM
  #3
David Young's Avatar
David Young
2nd Gear Member

Joined: Jul 2012
Posts: 375
From: Clinton, Tennessee
Default

If you take a good look at your factory exhaust manifolds on your 4.0, you'll see they are pretty much shorty headers. Like Dino Dino Bambino said, "you'll probably add 5 horsepower" .
Old Mar 4, 2020 | 09:38 AM
  #4
proeagles's Avatar
proeagles
4th Gear Member

Joined: Dec 2008
Posts: 1,621
From: LA
Default

Waste of money but they look good. Lot of trouble for pretty much no performance gain.
Old Mar 4, 2020 | 12:07 PM
  #5
Dino Dino Bambino's Avatar
Dino Dino Bambino
4th Gear Member

Joined: Oct 2014
Posts: 1,620
From: Cyprus (EU)
Default

Originally Posted by David Young
If you take a good look at your factory exhaust manifolds on your 4.0, you'll see they are pretty much shorty headers.
Yup, albeit with much shorter runners.

https://www.autopartone.com/products...t-manifold-set
Old Mar 5, 2020 | 05:53 AM
  #6
David Young's Avatar
David Young
2nd Gear Member

Joined: Jul 2012
Posts: 375
From: Clinton, Tennessee
Default

Originally Posted by Dino Dino Bambino
Yup, albeit with much shorter runners.

https://www.autopartone.com/products...t-manifold-set

True but the 4.0 exhaust manifolds look a lot better than the factory ones on my 2011 3.7 .

Old Mar 6, 2020 | 12:36 AM
  #7
Dino Dino Bambino's Avatar
Dino Dino Bambino
4th Gear Member

Joined: Oct 2014
Posts: 1,620
From: Cyprus (EU)
Default

Yeah, the 3.7 exhaust manifolds look very similar to those on the 4.6 3V. Their streamlined design is a lot better than the older log type manifolds but they're still restrictive in terms of flow. Mid-length shorty headers (e.g. JBA, BBK) offer some benefit on these engines with torque gains mainly at low/medium rpm, and can be worthwhile in states where long tube headers are illegal.

Last edited by Dino Dino Bambino; Mar 6, 2020 at 03:58 AM.
Old Mar 11, 2020 | 05:37 PM
  #8
Siber Express's Avatar
Siber Express
3rd Gear Member

Joined: Mar 2010
Posts: 761
From: Clinton, Tennessee
Default

To the OP, you will probably pick up some much needed low end HP and Torque, the 3.7 does a better job with Shorties but the 4.0 still makes gains
Originally Posted by Dino Dino Bambino
Yeah, the 3.7 exhaust manifolds look very similar to those on the 4.6 3V. Their streamlined design is a lot better than the older log type manifolds but they're still restrictive in terms of flow. Mid-length shorty headers (e.g. JBA, BBK) offer some benefit on these engines with torque gains mainly at low/medium rpm, and can be worthwhile in states where long tube headers are illegal.
I have Short Tube BBK's on my 3.7 and there was substantial gains in the lower to mid RPM and truthfully wish they had Short tubes for the F150 6.2. Dino, what state are Long tubes legal in since the law being broken is Federal on moving your Cat from their OEM location. There are just states where you can get away with long tubes.

Old Mar 11, 2020 | 08:29 PM
  #9
Spree's Avatar
Spree
1st Gear Member

Joined: Aug 2019
Posts: 55
From: Indiana
Default

You can get away with anything in Indiana. No inspections or emissions testing. Just watching this thread for information. Carry on!
Old Mar 26, 2020 | 09:24 AM
  #10
morriLinda1's Avatar
morriLinda1

Joined: Mar 2020
Posts: 2
From: WA
Default

Originally Posted by proeagles
Waste of money but they look good. Lot of trouble for pretty much no performance gain.
Agree. I supposed it should be equal in length pipes
